ESP-32S CAM WiFi Bluetooth Camera Module With OV3660 3MP Camera
The ESP-32S CAM WiFi Bluetooth Camera Module with OV3660 3MP Camera is a compact, powerful, and cost-effective solution for wireless image capture and IoT-based vision applications. Built around the ESP32-S chip, this module integrates WiFi and Bluetooth connectivity, making it ideal for remote monitoring, surveillance systems, and smart automation projects.
Equipped with the high-resolution OV3660 Camera Sensor, it delivers clear 3MP images and supports various image formats, ensuring excellent performance for both still image capture and video streaming. Its small form factor and low power consumption make it suitable for battery-operated and space-constrained applications.
The module supports multiple operating modes, including deep sleep for energy-efficient operation, and can be easily programmed using popular platforms like Arduino IDE and ESP-IDF. With built-in microSD card support, users can store captured images and videos locally for later use.
Features
- Built-in WiFi and Bluetooth connectivity
- High-quality 3MP camera using OV3660 sensor
- Supports image capture and video streaming
- MicroSD card slot for storage
- Low power consumption with deep sleep mode
- Compact and easy-to-integrate design
- Compatible with Arduino IDE and ESP-IDF
General Specifications
- Module Name: ESP-32S CAM
- Controller: ESP32-S
- Camera Sensor: OV3660
- Image Resolution: Up to 2048 × 1536 (3MP)
- Architecture: 32-bit Xtensa LX6 dual-core processor
- MicroSD Card Slot: Yes
- Max Supported Capacity: Up to 32 GB (FAT32)
- Processor & Memory
- CPU Frequency: Up to 240 MHz
- SRAM: 520 KB
- PSRAM: 4 MB (external)
- Flash Memory: 4 MB (typical)
- Wireless Connectivity
- WiFi: 802.11 b/g/n (2.4 GHz)
- Bluetooth: Bluetooth 4.2 BR/EDR + BLE
- Antenna: Onboard PCB antenna (IPEX connector optional in some variants)
- Sensor Type: CMOS
- Lens: Fixed focus
- Output Format: JPEG, BMP, Grayscale
- Field of View: ~65° (varies by lens)
- Interface: SCCB (I2C-like control interface)
- Frame Size Support:
- UXGA (1600×1200)
- SXGA (1280×1024)
- XGA (1024×768)
- SVGA (800×600)
- VGA (640×480)
- CIF/QVGA/QQVGA
Package Includes
- 1 x ESP32 CAM WiFi Module.
- 1 x OV3660 Camera Module 3MP.
