LILYGO T5 4.7 Inch E-paper V2.3 ESP32-S3 WI-FI Bluetooth Module - Solder Version (H580)

LILYGO T5 4.7 Inch E-paper V2.3 ESP32-S3 WI-FI Bluetooth Module - Solder Version (H580)

This is an LILYGO T5 4.7 Inch E-paper V2.3 ESP32-S3 WI-FI Bluetooth Module - With Female Header (H580). The LILYGO 4.7inch E-paper comes with ESP32-S3-WROOM-1-N16R8 MCU with Wi-fi Bluetooth V5.0 wireless connectivity. Onboard 16MB Flash & 8MB PSRAM, Which support PCF8563 RTC Battery capacity detection and 540 x 960 resolution.

User Manual / Datasheet / Example Codes Etc.

Specifications

• MCU : ESP32-S3-WROOM-1-N16R8
• Wireless Connectivity : Wi-fi Bluetooth V5.0
• Programming Environment : Arduino-ide VS Code

Onboard Functions

• Flash : 16MB
• PSRAM : 8MB
• Support PCF8563 RTC : Battery capacity detection

 4 . 7-inch Ultra-low Power E-paper

• Driver IC : EDO47TC1
• Size : 4.7 inch
• Gray levels : 16
• Resolution : 540 x 960 pixels
• Ultra Wide viewing angle : low power consumption

Package Includes

• 1x T5 4.7 Inch E-paper V2.3
• 1x JST 2.0mm 2Pin

What's On Board

Pin Daigram
