2.13inch E-Paper HAT (G), 250x122, Red/Yellow/Black/White, SPI Interface

This is a 2.13inch E-Paper HAT (G), 250x122, Red/Yellow/Black/White, SPI Interface. The 2.13inch E-paper HAT G comes with display color Red/Yellow/Black/White with spi interface and 250x122 resolution, Which support Raspberry Pi/Jetson Nano/Arduino/STM32 etc.

User Manual / Datsheet / Example Codes Etc.

Features

No backlight, keeps displaying last content for a long time even when power down
Ultra low power consumption, basically power is only required for refreshing
SPI interface, for connecting with other controller boards like Raspberry Pi/Jetson Nano/Arduino/STM32, etc.
Onboard voltage translator, compatible with 3.3V/5V MCUs
Comes with online development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32)

Specifications

OPERATING VOLTAGE : 3.3V/5V
DISPLAY COLOR : Red/Yellow/Black/White
INTERFACE : 3-wire SPI, 4-wire SPI
GREY SCALE : 2
OUTLINE DIMENSIONS : 65 × 30.2mm
FULL REFRESH TIME : 25s
DISPLAY SIZE : 48.55 × 23.70mm
REFRESH POWER : <10mW
DOT PITCH : 0.1943 × 0.1942mm
STANDBY CURRENT : <0.01uA (almost none)
RESOLUTION : 250 × 122 pixels
VIEWING ANGLE : >170°

Onboard SPI Control Interface

For Use With Controller Boards Like Arduino/STM32

VCC : Power (3.3V / 5V input)
GND : Ground
DIN : SPI MOSI pin
SCLK : SPI SCK pin
CS : SPI chip selection, low active
DC : Data/Command selection (high for data, low for command)
RST : External reset, low active
BUSY : Busy status output pin (high for busy)

Onboard Voltage Translator

Compatible With 3.3V / 5V MCUs

Dimensions
