Heltec ESP32-S3 MCU + SX1262 LoRa 868MHz Wireless Stick(V3) Development Board With 0.49inch OLED Display

Heltec ESP32-S3 MCU + SX1262 LoRa 868MHz Wireless Stick(V3) Development Board With 0.49inch OLED Display

Wireless Stick is a development board for Wi-Fi, Bluetooth and LoRa. Its functions are basically the same as “WiFi Lora 32”, except that the screen is reduced to 0.49 inch and a shielding shell is added.

The Wireless Stick is composed up of an MCU (ESP32-S3FN8) and Semtech LoRa Transceivers (SX1262), perfectly support Arduino. Users can easily carry out secondary development and application.

User Manual / Datasheet / Example Codes Etc.

Features

• Microprocessor: ESP32-S3FN8 (Xtensa® 32-bit LX7 dual core processor, five stage pipeline rack Structure, main frequency up to 240 MHz).
• SX1262 LoRa node chip.
• Type-C USB interface with a complete voltage regulator, ESD protection, short circuit protection, RF shielding, and other protection measures.
• Onboard SH1.25-2 battery interface, integrated lithium battery management system (charge and discharge management, overcharge protection, battery power detection, USB / battery power automatic switching).
• Integrated WiFi, LoRa, Bluetooth three network connections, onboard Wi-Fi, Bluetooth dedicated 2.4GHz metal spring antenna, reserved IPEX (U.FL) interface for LoRa use.
• Onboard 0.49-inch 64*32 dot matrix OLED display, which can be used to display debugging information, battery power, and other information.
• Integrated CP2102 USB to serial port chip, convenient for program downloading, debugging information printing.
• Support the Arduino development environment.
• We provide ESP32 + LoRaWAN protocol Arduino® library, this is a standard LoRaWAN protocol that can communicate with any LoRa gateway running the LoRaWAN protocol. In order to make this code running, a unique license is needed.
• With good RF circuit design and low-power design.

Specifications

• Master Chip: ESP32-S3FN8 (Xtensa®32-bit lx7 dual core processor)
• LoRa Node Chip: SX1262
• USB to Serial Chip: CP2102
• Frequency: 863~928MHz
• Max. TX Power: 21 ± 1 dBm
• Max. Receiving Sensitivity: -134dBm
• Wi-Fi: 802.11 b/g/n, up to 150Mbps
• Bluetooth: Bluetooth LE: Bluetooth 5, Bluetooth mesh
• Display: 0.49-inch OLED
• Memory: 384KB ROM; 512KB SRAM; 16KB RTC SRAM; 8MB SiP Flash
• Battery: 3.7V lithium battery power supply and charging
• Operating temperature: -20 ~ 70 ℃
• Dimensions: 58.08 * 22.6* 8.2 mm
• Interface:
• Type-C USB;
• 2*1.25 lithium battery interface;
• LoRa ANT(IPEX1.0);
• 2*17*2.54 Header Pin

Package Includes

• 1x Wireless Stick
• 1x Glue Rod Antenna
• 1x SH1.25×2 Battery Connector
• 1x Pin Map Sticker

Pin Diagram
