DWIN 2.8inch Circular LCD, Capacitive Touch, IPS TFT 480x480 300nit Bright LCD Display LI48480T028BA3098-TCF
This is anDWIN 2.8inch HMI Serial Circular LCD, Capacitive Touch, IPS TFT 480x480 300nit Bright LCD Display LI48480T028BA3098-TCF. The Dwin 2.8inch Circular TFT LCD comes with 300nit brightness 16.7 millons RGB colors with OCA bonding capacitive touch panel, Which support ST7701S driver ic chip.
Features
- 2.8 inch, 480×480 pixels, IPS wide viewing angle circular TFT LCD
- 16.7M color, RGB_24bit 40PIN_0.5mm interface, 300 cd/m², ST7701S Driver IC
- OCA bonding capacitive touch panel can be realized
- OEM A-grade glass, no bad pixels, full inspection, 30 days charged aging process
Specifications
- Color : 16.7M
- LCD Type : IPS-TFT-LCD
- Viewing Angle : Wide viewing angle, 85/85/85/85(L/R/U/D)
- Display Area(A.A) : 70.13(W)*70.13(H)
- Driver IC : ST7701S
- Luminance : 300cd/m²
- LED Numbers : 4 LEDS
- Interface : RGB_24bit 40PIN_0.5mm
Electrical Characteristics
- Analog Voltage : 2.8V(Typ.)
- Forward Voltage : 12V(Typ.)
- Forward Current : 20mA
- Uniformity(with L/G) : 80%
- LED Life-Time : 30000 Hr
- Power Consumption : 240mW
Optical Characteristics
- Contrast Ratio : 1200:1
- Response Time : 35ms
- Color Gamut : 65%
