LILYGO T-Encoder Pro ESP32-S3 Rotary Encoder Circuit Board With 1.2inch AMOLED Touch Display (K249)
T-Encoder-Pro is a smart control knob equipped with a AMOLED screen, developed based on the ESP32S3R8 chip, which is controlled by a dial.
The Lilygo T-Encoder Pro ESP32-S3 is a cutting-edge control solution, integrating a high-performance ESP32-S3 chip with a 1.2-inch AMOLED touch display. This versatile device serves as a sophisticated rotary encoder, offering precise control and a vivid, responsive interface. Perfect for hobbyists and developers alike, the T-Encoder Pro is designed for a wide range of applications, from smart home projects to advanced robotics. Its compact design and powerful features make it an essential tool for innovative, user-friendly control systems.
User Manual / Datasheet / Example Codes Etc.
Specifications
- MCU: ESP32-S3 R8
- Flash: 16MB
- PSRAM: 8MB
- Wireless protocol: 2.4 GHz Wi-Fi and Bluetooth 5 (LE)
- Onboard functions: Buzzer PIN--IO17, 2 x Qwiic 4-Pin
Display Specs
- Size: 1.2-inch round screen
- Screen Type: AMOLED
- Driver Chip: SH8601A-W14-T06
- Compatibility Library: Arduino_GFX
- Bus Communication Protocol: QSPI
Touch
- Chip: CHSC5816
- Bus Communication Protocol: IIC
Rotary Encoder
- Characteristic: Supports left and right rotation
Package Includes
- 1x LILYGO T-Encoder Pro
Pin Diagram
