LILYGO T-RGB ESP32-S3 2.1inch Full Round Circle Display LCD (H597)

LILYGO T-RGB ESP32-S3 2.1inch Full Round Circle Display LCD (H97)

T-RGB is a development board whose main control chip is ESP32-S3. It is equipped with a 2.1-inch LCD color screen (3SPI&RGB interface) and CST820 touch chip. It has a TF card reading and writing function and is equipped with a programmable button and a set of IIC pins. It can be powered with a lithium battery and charged with a USB. You can use the ESP32S3 directly for USB communication or programming.

User Manual / Datasheet / Example Codes Etc.

Specifications

• MCU : ESP32-S3R8 Dual-core LX7 microprocessor
• Wireless Connectivity : Wi-Fi 802.11, BLE 5 + BT mesh
• Programming Platform : Arduino-ide, VS Code

Onboard functions:

• PSRAM : 16MB
• Flash : 8MB
• Button : Boot; Reset
• Bat voltage detection : IO04
• TF-Card Slot

2.1 inch ST7701S IPS TFT LCD:

• Resolution : 480(H) X 480(V) RGB Full Color
• Interface : 3-wire SPI + 18bit RGB interface
• Drive IC : ST7701S
• Display Type : 2.1-inch TFT LCD

Pin Daigram
