DWIN 5.0inch TN TFT LCD, Capacitive Touch, TN TFT 800x480 300nit LCD Display, LN80480T050IA4098-TCF
The DWIN 5.0inch TN TFT LCD display, a compact yet powerful solution for your visualization needs. Engineered with precision and reliability in mind, this display offers a crisp and clear viewing experience suitable for a wide range of applications.
Features
- 5 inch, 800×480 pixels, TN normal viewing angle TFT LCD
- 16.7M color, 300 cd/m², RGB_24bit 40PIN_0.5mm interface, 12 LEDS
- Air bonding capacitive touch panel
Specifications
- Color: 16.7M
- LCD Type: TN-TFT-LCD
- Viewing Angle: Normal viewing angle, 70/70/50/70(L/R/U/D)
- Display Area(A.A): 108.0(W)*64.8(H)
- Driver IC: ILI6122/ILI6137A-00T004/EK9713CA+ ILI5960/EK73002AB2
- Luminance: 300cd/m²
- LED Numbers: 12 LEDS
- Interface: RGB_24bit 40PIN_0.5mm
Touch Specifications
- Type: CTP (Capacitive touch panel)
- Structure: G+G
- Control Type: GT911
- Outline Size(mm): 119.25(L)*77.03(W)*1.98(T)
- View Area(mm): 108.60(L)*65.40W)
- Surface Hardness: 6H
- Light Transmittance: ≧85%
- Operating Temperature: -20~70℃
- Storage Temperature: -30~80℃
Electrical Characteristics
- Digital Power Voltage:3.3V(Typ.)
- Voltage for LED Backlight: 18V(Typ.)
- Current for LED Backlight: 40mA
- Uniformity(with L/G): 80%
- LED Life-Time: 30000 Hr
Optical Characteristics
- Contrast Ratio: 500:1
- Response Time: 35ms(Type)
- Color Gamut: 55%
