Luckfox Pico Pi A W 256MB Ram + 8GB eMMC Wireless Linux Micro Development Board - Based On RV1106G3 - Wi-Fi 6 & BLE 5.2 - Supports Intelligent Encoding, Built-in Self-developed Third-generation ISP3.2 [ SIM7600G-H-M.2 4G module Not Included]

The Luckfox Pico Pi is a cost-effective Linux micro development board, based on the Luckfox Core1106 chip to provide a simple and efficient development platform for developers. Supports a variety of interfaces including MIPI CSI, GPIO, UART, SPI, 12C, USB, and an M.2 slot for 4G module, etc., which is ideal for a wide range of embedded applications.

User Manual / Datasheet / Example Codes Etc.

Specifications

Model: Luckfox Pico Pi A
Processor: RV1106G3
NPU: 1TOPS
Memory: 256MB DDR3L
eMMC: 8GB
VEPU: Supports H264/H265 video encoding
ISP: Maximum 5M @30fps input
Wi-Fi+Bluetooth: 2.4GHz WiFi6 Bluetooth 5.2/BLE
POE Port: IEEE 802.3af PoE
Ethernet: 10/100M Ethernet controller and embedded PHY
Camera Interface: 1 x MIPI CSI 2-lane
Audio:

1 x Surface-mount microphone
1 x Microphone expansion port (MX1.25mm-2P)
1 x 3.5mm audio output

USB:

1 x USB Device
4 x USB HOST 2.0 (HUB expansion)

RTC: 1 x RTC Port（SH1.0-2P）
Storage Expansion: 1 x MicroSD slot (storage-only, no system boot support)
Mobile Connectivity:

1 x Nano SIM slot
1 x 4G module M.2 slot (supports SIM7600G-H-M.2 4G module)

GPIO: Based on Raspberry Pi 40Pinout

Package Includes

Luckfox Pico Pi A W x1
IPX 2.4G 2DB antenna x1
4G Module mounting screw x1

Pin definition

What's On Board

Dimensions
