PCIe To 2-Ch M.2 Adapter Type B for Raspberry Pi 5, Compatible with 2280 / 2260 / 2242 / 2230 size NVMe Protocol M.2 SSD, Raspberry Pi 5 NVMe HAT
PCIe TO 2-CH M.2 HAT+ (B) is a PCIe to M.2 M key adapter board designed for Raspberry Pi 5, is compatible with M.2 solid state drive in 2230/2242/2260/2280 size, only supports Gen2 mode and does not support booting Pi5 from SSD.
User Manual / Datasheet / Example Codes Etc.
Features
- Support NVMe protocol and M.2 solid state drive protocol, high-speed read/write, with high work efficiency.
- PCI-E×1 only supports Gen2 modes.
- Only supports PI5B.
- Compatible with M.2 solid state drive in 2230/2242/2260/2280 sizes.
- Onboard working indicator lights, with PWR on continuously when powered, and ACT blinking during read/write.
- HAT+ design with onboard EEPROM chip.
- Onboard power monitoring chip for real-time monitoring the operation status of the solid state drive.
- Support NVME SSD booting.
Package Includes
- 1x PCIe TO 2-CH M.2 HAT+ (B)
- 1x 16P-Cable-40mm
- 1x Standoff pack
Connecting To PI5 Via 16PIN Cable
Based On 16PIN PCIe Interface Of Raspberry Pi 5
Dual NVMe Solid State Drives Support
Compatible With 2280 / 2260 / 2242 / 2230 Size M.2 Solid State Drives
Supports PCIE X1 Gen2 Only, Supports Booting PI5 From Solid State Drive
Onboard Dual LED Indicators
Easy To Monitor The Working Status
Onboard Power Monitoring Chip And EEPROM
Real-Time Monitoring Of Solid State Drive Power Status For More Stable Operation
Dimensions
