SIM7020E NB-IoT Module For Raspberry Pi Pico

SIM7020E NB-IoT Module For Raspberry Pi Pico

The Pico-SIM7020E-NB-IoT is an NB-IoT (NarrowBand-Internet of Things) module designed for Raspberry Pi Pico. It supports multiple NB-IoT frequency bands, can be controlled via serial AT commands, and supports communication protocols like HTTP/MQTT/LWM2M/COAP, etc. Due to the advantages of low delay, low power, low cost, and wide coverage, it is the ideal choice for IoT applications such as intelligent instruments, asset tracking, remote monitoring, and so on.

User Manual / Datasheet / Example Codes Etc.

Features

• Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series boards.
• UART communication, serial AT commands control, multiple communication protocols support, multiple cloud platform support.
• Integrates 3.7V Li-po battery connector and recharge circuit, allows being powered from external rechargeable Li-po battery, or recharge it in turn.
• 2 x LED indicators, for monitoring the module operating status.
• Onboard Nano SIM card slot for NB-IoT specific card.
• Comes with development resources and manual (MicroPython examples).

Specifications

OPERATING FREQUENCY

• NB-IoT : B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/ B20/B25/B26/B28/B66/B71/B85
• Cat-M : B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85
• GNSS : GPS, GLONASS, BeiDou, Galileo
• APPLICABLE REGION : Global

DATA TRANSMISSION

• NB-IoT(Kbps) : 136(DL)/150(UL)
• Cat-M(Kbps) : 589(DL)/1119(UL)

OTHERS

• COMMUNICATION PROTOCOL : TCP/UDP/HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT...
• POWER SUPPLY : Lithium battery header or the USB port of the Raspberry Pi
• LITHIUM BATTERY HEADER : 3.7V ~ 4.2V
• LOGIC LEVEL : 3.3V

SINGLE MODULE CURRENTS

• Idle mode: 10mA
• Sleep mode: 1.2mA
• PSM mode: 3.2uA

Indicator

• NET：Network indicator

• Charge: charging indicator

• SWITCH : Lithium battery power on/off
• SIM card : NB-IoT / Cat-M card (only supports 1.8V)
• Antenna : LTE, GNSS
• Dimensions : 73.5 × 24.00mm

Package Includes

• Pico-SIM7020E-NB-IoT x1
• Antenna x1
• 20PIN female pin header x2
• 40PIN male pin header × 1
• 3.7V rechargeable Li-po battery x1

Cloud Communication

Application Example

Pinout Definition

Dimensions
