SIM7080G NB-IoT / Cat-M(eMTC) / GNSS Module for Raspberry Pi Pico, Global Band Support

The Pico-SIM7080G-Cat-M/NB-IoT is an NB-IoT (NarrowBand-Internet of Things), Cat-M (aka eMTC, enhanced Machine Type Communication), and GNSS (Global Navigation Satellite System) module designed for Raspberry Pi Pico. It supports multiple NB-IoT frequency band, can be controlled via serial AT commands, and supports communication protocols like HTTP/MQTT/LWM2M/COAP, etc. Due to the advantages of low delay, low power, low cost, and wide coverage, it is the ideal choice for IoT applications such as intelligent instruments, asset tracking, remote monitoring, and so on.

User Manual / Datasheet / Example Codes Etc.

Features

Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series boards.
UART communication, serial AT commands control.
Communication protocol support: TCP/UDP/HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT...
GNSS positioning support: GPS, GLONASS, BeiDou, and Galileo.
Integrates 3.7V Li-po battery connector and recharge circuit, allows being powered from external rechargeable Li-po battery, or recharge it in turn.
2 x LED indicators, for monitoring the module operating status.
Onboard Nano SIM card slot, supports ONLY 1.8V SIM card (3V SIM card is not available).
Comes with development resources and manual (MicroPython examples).

Specifications

FREQUENCY BAND

NB-IoT : B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85
Cat-M : B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85
GNSS : GPS, GLONASS, BeiDou, Galileo
Applicable region : global applicable

DATA RATE

NB-IoT(Kbps) : 136(DL)/150(UL)
Cat-M(Kbps) : 589 (DL)/1119 (UL)

OTHERS

Communication protocol : TCP/UDP/HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT
Power supply : External Li-po battery OR Raspberry Pi Pico USB port
Battery interface : 3.7V ~ 4.2V
Logic level : 3.3V
Indicator NET：NET: network indicator Charge: recharge indicator
Switch : Li-po battery power supply switch
SIM card : NB-IoT / Cat-M card (1.8V ONLY)
Antenna connector : LTE, GNSS
Dimensions : 73.5 × 24.00mm

Package Includes

1x Pico-SIM7080G-Cat-M/NB-IoT
1x LTE antenna
1x GPS antenna
2x 20PIN female pin header
1x 40PIN male pin header
1x 3.7V rechargeable Li-po battery

Cloud Communication

Supports Communication Protocols Including: TCP/UDP/HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT

Application Example

Pinout Definition

Outline Dimensions
