2.42inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication - Yellow
₹​1,297.00
₹​1,099.15 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 11
B2B GST Credit Available
Price in reward points: 1099

2.42inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication - Yellow

This is a 2.42-inch OLED module - Yellow, a built-in SSD1309 driver chip, using the SPI/I2C interface communication, provides Raspberry Pi, Arduino, STM32, ESP32, Jetson Nano, and other demo information.


User Manual / Datasheet / Example Codes Etc.


Features

  • Ultra-narrow bezel, conpact size, with onboard voltage translator
  • Adopts 4-wire SPI and I2C interfaces, better compatibility, fast data rate
  • Comes with online development resources (examples for Raspberry Pi/Raspberry Pi Pico/Arduino/STM32/ESP32/Jetson Nano)


Specifications

  • OPERATING VOLTAGE : 3.3V / 5V
  • DISPLAY PANEL : OLED
  • RESOLUTION : 128 × 64 pixels
  • PIXEL SIZE : 0.4 × 0.4mm
  • COMMUNICATION INTERFACE : 4-wire SPI (default) / I2C
  • DRIVER : SSD1309
  • DISPLAY SIZE : 55.01 × 27.49mm
  • MODULE SIZE : 61.50 × 39.50mm


Package Includes

  • 1x 2.42inch OLED Module
  • 1x GH1.25 7PIN cable



2.42inch OLED Display Module

Embedded SSD1309 Driver Chip, SPI / I2C Communication




Control Interface


Hardware Connection

Connecting With Raspberry Pi Via SPI Interface



Connecting With Arduino Board Via SPI Interface



Usage Example




Dimensions
