1.32inch OLED Display Module, 128×96 Resolution, 16 Gray Scale, SPI / I2C Communication

This is a 1.32inch OLED Display Module, 128×96 Resolution, 16 Gray Scale, SPI / I2C Communication. The 1.32inch OLED Display Comes with SPI / I2C Interface, SSD1327 Driver, Resolution 128 × 96 pixels, pixel size 0.19 × 0.19 mm, which Support Raspberry Pi/Arduino/STM32 Etc.

User Manual / Datasheet / Example Codes Etc.

Features

Ultra-narrow bezel, conpact size, with onboard voltage translator
Adopts 4-wire SPI and I2C interfaces, better compatibility, fast data rate
Comes with online development resources (examples for Raspberry Pi/Arduino/STM32)

Specifications

OPERATING VOLTAGE : 3.3V / 5V
DISPLAY PANEL : OLED
RESOLUTION : 128 × 96 pixels
PIXEL SIZE : 0.19 × 0.19 mm
COMMUNICATION INTERFACE : 4-wire SPI / I2C
DRIVER : SSD1327
DISPLAY SIZE : 26.86 × 20.14mm
MODULE SIZE : 34.30 × 30.50mm

Control Interface

RES Reset, low active
DC Data/Command selection (high for data, low for command)
CS Chip selection, low active
CLK Clock input
DIN Data input
GND Ground
VCC Power (3.3V / 5V input)

Usage Example

Dimensions
