0.96inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication
₹​434.24
₹​368.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 4
B2B GST Credit Available
Price in reward points: 368

0.96inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication

User Manual / Datasheet / Example Codes Etc.

Features

  • Operating voltage: 3.3V/5V (IO high-level voltage is as same as the power supply.)
  • Communication interface: 4-wire SPI / I2C
  • Screen type: OLED
  • Control chip: SSD1315
  • Resolution: 128 × 64 Pixels
  • Outline dimensions: 26.0mm × 26.0mm
  • Display size: 21.74mm × 11.18mm
  • Display colors: Blue/White/Blue and Yellow (1/4 yellow on the top)
  • Operating temperature: -20°C ~ 70°C
  • Storage temperature: -30°C ~ 80°C
  • Viewing angle: > 160°

Package Includes

  • 0.96inch OLED Module x1
  • Jumper cable female-female 7PIN x1


0.96inch OLED Display Module

Embedded SSD1315 Driver Chip, SPI / I2C Communication Comes with examples for Raspberry Pi, Arduino, STM32, etc.

Hardware Connection

Connecting With Raspberry Pi Via SPI InterfaceConnecting With Arduino Board Via SPI Interface


Dimensions
