TTGO LoRa 868MHz ESP32 Development Board T3 V1.6.1 CH9102F SMA IP5306 (Q168 )

A generic LoRa and ESP32 based development board. Can be used for a variety of applications.

Specifications:

• Working voltage: 1.8~3.7v
• Acceptable current：10~14mA
• Transmit current: 120mA@+20dBm

                              90mA@+17dBm

                              29mA@+13dBm

• Operating frequency: 868MHz
• Transmit power: +20dBm
• Receive sensitivity :-139dBm@LoRa &62.5Khz&SF=12&146bps

          -136dBm@LoRa &125Khz&SF=12&293bps

          -118dBm@LoRa &125Khz&SF=6&9380bps

          -123dBm@FSK&5Khz&1.2Kbps

• Frequency error：+/-15KHz
• FIFO space：64Byte
• Data rate：1.2K~300Kbps@FSK

                   0.018K~37.5Kbps@LoRa

• Modulation Mode ：FSK,GFSK,MSK,GMSK,LoRa TM，OOK
• Interface form ：SPI
• Sleep current ：0.2uA@SLEEP

                           1.5uA@IDLE

• Operating temperature：-40℃- +85℃
• Digital RSSI function
• Automatic frequency correction
• Automatic gain control
• Fast wake-up and frequency hopping
• The highly configurable data packet handler
• SMA Antenna

Additional Resources:

Codes, Documentation, and Instructions

Paxcounter Project using this board

Package Includes:
