RM520N-GL PCIe to 5G HAT+ for Raspberry Pi 5, High-Speed Networking, Support PCIe Protocol, Raspberry Pi 5 HAT

PCIe to 5G M.2 adapter plate is designed specifically for Raspberry Pi 5, compatible with 3042/3052 size 5G modules, supporting Gen2 mode and high-speed communication.

RM520N-GL is a 5G sub-6GHz module designed for IoT/EMBB applications. Adopts the 3GPP Release16 technology and supports 5G non-standalone (NSA) and standalone (SA) modes. Designed in an M.2 form factor, RM520N-GL is compatible with Quectel RM50xQ 5G module, LTE-A Cat 6 module EM06, Cat 12 modules EM12/EM12xR/EM121R-GL, and Cat 16 module EM160R-GL, which facilitate the migration from LTE-A to 5G. This industrial-grade module is for industrial and commercial applications.

User Manual / Datasheet / Example Codes Etc.

Features

Support PCIe protocol 5G M.2 interface communication protocol, high-speed communication, low delay.
PCI-E x1 Gen2 mode.
Only support Raspberry Pi 5.
Compatible with 3042 / 3052 sized 5G M.2 communication modules.
Onboard operation indicator, PWR indicator normally on when power on; When using SIM8262 series modules, NET indicator blinking when registering the network; and it is normally on when RM5xx series modules are used. It is easy to learn the working status.
HAT+ design, with onboard EEPROM chip.
Onboard power monitoring chip, real-time monitoring the working status of 5G modules.
Reserve fan vent and the mounting holes to reserve air ducts for PI5 fans, increase air flow and reduce module temperature.

Specifications

MODEL: RM520N-GL 5G HAT+
5G Module: RM520N-GL
5G Standard: 3GPP R16
5G: Sub-6 GHz
Applicable Region: Global
Dimensions: 30.0 × 52.0 × 2.3 (mm)

Frequency Band 5G

5G NR NSA: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79
5G NR SA: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79

LTE

LTE-FDD: B34, B38, B39, B40, B41, B42, B43, B48
LTE-TDD: B34, B38, B39, B40, B41, B42, B43, B48
LAA: B46

UMTS

WCDMA: B1, B2, B4, B5, B8, B19
GNSS: GPS / GLONASS / BeiDou(Compass) / Galileo / QZSS (only RM520N-GL and RM530N-GL support)

Pacakge Includes

Connecting To PI5 Via PCIe Interface

Onboard Power Monitoring Chip And EEPROM

Pinout Definition

Dimensions
