ROCK64 MEDIA BOARD COMPUTER - 4GB RAM - RK3328 Quad-Core ARM Cortex A53 64-Bit Processor
This item is 4GB RAM variant of ROCK64 Media Board Computer.

RK3328 SoC based single board computer with 4K video processing capabilities. Ideal for high performance portable computing at low cost.
The board supports various operating system including Android 7.1, Debian, Yocto Linux, and more. Some of the source code and software development tools are already available in github.
Visit manufacturer page for more details and resources
ROCK64 board specifications:
- SoC – Rockchip RK3328 quad core Cortex A53 processor with ARM Mali-450MP2 GPU
- System Memory – 2 GB LPDDR3 @ 1600 MHz
- Storage – eMMC flash module socket + micro SD card slot + 128 Mbit SPI flash
- Video & Audio Output – HDMI 2.0a up to 4K @ 60 Hz with HDR10 and HLG support, 3.5mm AV port (composite video + stereo audio)
- Video Codec – 4K VP9, H.265 and H.264, 1080p VC-1, MPEG-1/2/4, VP6/8
- Connectivity – Gigabit Ethernet
- USB – 2x USB 2.0 ports, 1x USB 3.0 port
- Expansion Headers
- 40-pin Pi-2 Bus with GPIOs, 2x I2C, Analog inputs, UART, SPI, and power signals (5V, 3.3V, and GND)
- 22-pin Pi-P5+ Bus with GPIOs, I2S, S/PDIF, Ethernet, and power signals (5V, 3.3V, and GND)
- Misc – IR receiver; power, recovery & reset buttons; eMMC jumper
- Power Supply – 5V/3A via 3.5mm/1.35mm power barrel
- Dimensions – 85 x 56 mm
