RP2040-Plus, a Pico-like MCU Board Based on Raspberry Pi MCU RP2040, Onboard 16MB Flash Memory - Without Pinheader

This is an RP2040 MCU Board, a Pico-like MCU Board. The RP2040-Plus MCU board based on RP2040 Dual-Core Arm Cortex M0+ processor running up to 133 MHz. it features an onboard 16MB Flash, USB-C connector, recharge header, and higher current DC-DC chip.

User Manual / Datasheet / Example Codes Etc.

Specifications

RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom.
Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz.
264KB of SRAM, and 16MB Flash memory.
USB-C connector, keeps it up to date, easier to use.
Lithium battery recharge/discharge header, suitable for mobile devices.
Onboard DC-DC chip TPS63000, high-efficiency DC-DC buck-boost chip, 1.8A current switch.
The castellated module allows soldering directly to carrier boards.
USB 1.1 with device and host support.
Low-power sleep and dormant modes.
Drag-and-drop programming using mass storage over USB.
26 × multi-function GPIO pins.
2 × SPI, 2 × I2C, 2 × UART, 3 × 12-bit ADC, 16 × controllable PWM channels.
Accurate clock and timer on-chip.
Temperature sensor
Accelerated floating-point libraries on-chip.
8 × Programmable I/O (PIO) state machines for custom peripheral support.

RP2040 MCU Board 16MB Flash Memory - Unsolder Version

Dual-Core Arm Processor

Dual-Core Arm Cortex M0+ Processor, Flexible Clock Running Up To 133 MHz

26 × Multi-Function GPIO Pins

Configurable Pin Function, Allows Flexible Development And Integration

LED
user LED (not power indicator)
USB Type-C connector
ETA6096
high efficiency Lithium battery recharge manager
MP28164
high efficiency DC-DC buck-boost chip
BOOT button
press it when resetting to enter download mode
On-board flash memory
4MB: W25Q32JVSSIQ
16MB: W25Q128JVSIQ
RESET button

RP2040
dual-core processor, up to 133MHz operating frequency
Battery header
MX1.25 header, for 3.7V Lithium battery, allows recharging the battery and powering the board at the same time
Pinout
compatible with Raspberry Pi Pico
USB test points
connecting to USB interface
BOOT test point
connecting to BOOT button
DEBUG points

Outline Dimensions
