ADIY FLY Pico RP2040 Basic Board Type C

ADIY FLY Pico RP2040 Basic Board Type C

ADIY FLY RP2040 Type C comes with a large on-chip memory, symmetric dual-core processor complex, deterministic bus fabric, and rich peripheral set augmented with a unique Programmable I/O (PIO) subsystem, RP2040 provides professional users with unrivalled power and flexibility. ADIY FLY pairs RP2040 with 4MB of Flash memory, and a power supply chip supporting input voltages from 3.3-5.5V. It provides 27 GPIO pins, 4 of which can function as analogue inputs, on 2.54mm-pitch through-hole pads. The RESET button on ADIY FLY makes the usage of module easy. On Board LED is added to indicate the power supply.

RP2040 is manufactured on a modern 40nm process node, delivering high performance, low dynamic power consumption, and low leakage, with a variety of low-power modes to support extended-duration operation on battery power.

Datasheet

Features

• Pin to Pin as Compatible as Raspberry Pi Pico
• Type C connector
• With RESET Button
• With 4MB FLASH memory
• Dual-core Arm Cortex-M0+ processor, flexible clock running up to 133 MHz
• 264KB on-chip SRAM
• DMA controller
• Accelerated integer and floating-point libraries on-chip
• Drag-and-drop programming using mass storage over USB
• 2 on-chip PLLs to generate USB and core clocks
• 27 GPIO pins, 4 of which can be used as analog inputs
• 2 × UART, 2 × SPI controllers, 2 × I2C controllers, 16 × PWM channels
• 1 × USB 1.1 controller and PHY, with host and device support
• Accurate on-chip clock, Temperature sensor
• 8 × Programmable I/O (PIO) state machines for custom peripheral support
• High quality, low cost, high availability
• Simple yet highly flexible power supply architecture
• Various options for easily powering the unit from micro-USB, external supplies, or batteries
• Comprehensive SDK, software examples and documentation

Specifications

• Microcontroller: RP2040
• CPU: Dual-core Arm Cortex-M0+ processor, running at up to 133MHz
• Memory: 264KB on-chip SRAM; 4MB on-board Flash
• USB Connector : Type C
• Interfacing: 27 GPIO pins, including 4 analog inputs
• Input power: 3.3–5.5V DC.
• Reset button: Included

Package Includes

• 1x  RP2040 Basic Board Type C
