Name: RP2350 MCU Board, With 1.28inch Round LCD, Dual-core & Dual-architecture Design, 240×240 Pixels, 65K Color, IPS Panel - With CNC Metal Case
Brand: WaveShare Electronics
SKU: 28987
Price: 1816.00 INR
Availability: OutOfStock

RP2350 MCU Board, With 1.28inch Round LCD, Dual-core & Dual-architecture Design, 240×240 Pixels, 65K Color, IPS Panel - With CNC Metal Case

WaveShare Electronics

RP2350 MCU Board, With 1.28inch Round LCD, Dual-core & Dual-architecture Design, 240×240 Pixels, 65K Color, IPS Panel - With CNC Metal Case

Based on 0 reviews. - Write a review

₹1,816.00

₹1,538.98 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 15
B2B GST Credit Available

Price in reward points: 1539

Stock: 0 in Stock
SKU: 28987
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

RP2350 MCU Board, With 1.28inch Round LCD, Dual-core & Dual-architecture Design, 240×240 Pixels, 65K Color, IPS Panel - With CNC Metal Case

RP2350-LCD-1.28 is a low-cost, high-performance MCU board designed by Waveshare. Tiny size with onboard 1.28inch LCD round display, Li-ion battery recharge manager, 6-axis sensor (3-axis accelerometer and 3-axis gyroscope) and so on, adapting all GPIO and Debug pins, which makes it easy for you to develop and integrate it into products quickly.

User Manual / Datasheet / Example Codes Etc.

Features

RP2350 microcontroller chip designed by Raspberry Pi in the United Kingdom
Adopts unique dual-core and dual-architecture design: dual-core Arm Cortex-M33 processor and dual-core Hazard3 RISC-V processor, flexible clock running up to 150 MHz
520KB of SRAM, and 4MB of onboard Flash memory
Type-C connector, keeps it up to date, easier to use
Onboard 1.28inch 240×240 pixels 65K colorful IPS LCD display for clear color pictures
Lithium battery recharge/discharge header, suitable for mobile devices
All GPIO pins are adapted through 1.27 pitch female headers (There are 30 pins in total, but some pins have been connected to the internal circuit, please refer to the wiki for details when multiplexing)
USB 1.1 with device and host support
Low-power sleep and dormant modes
Drag-and-drop programming using mass storage over USB
2 × SPI, 2 × I2C, 2 × UART, 4 × 12-bit ADC, 24 × controllable PWM channels
Temperature sensor
12 × Programmable I/O (PIO) state machines for custom peripheral support

Specifications

MCU: RP2350
Display Size: 1.28inch
Display Type: IPS
Resolution: 240 x 240 pixels
Color Depth: 65K colors
Viewing Angle: Wide-angle IPS panel for clear visibility from multiple angles
Case Material: Metal

Package Includes

1x RP2350-LCD-1.28-B

CNC metal case

Adopts CNC metal case for fast heat dissipation, with Acrylic dull-polish bottom plate

30 × multi-function GPIO pins

configurable pin function, allows flexible development and integration

What's Onboard

Dimensions
