SIM8202G-M2 SIMCom Original 5G Module, M.2 Form Factor, High Throughput Data Communication
The SIM8202X-M2 is the Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ module which supports R15 5G NSA/SA up to 2.4Gbps data transfer.
It has strong extension capability with abundant interfaces including PCIe, USB3.1, GPIO etc. The module provides much flexibility and ease of integration for customer's applications.
The SIM8202X-M2 adopts M.2 form factor, TYPE 3042-S3-B. AT commands of SIM8202X-M2 are compatible with SIM7912G/SIM8200X-M2 series modules. This also minimizes the investments of customers and enables a short time-to-market.
It is designed for applications that need high throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for many applications.
Product Advantages
- Standard M.2 interface.
- High throughput data communication.
- AT commands of the SIM8202X-M2 are compatible with SIM7912G/SIM8200X-M2 series modules
Specifications
- 5G STANDARD : 3GPP R15
- CHIP : Qualcomm Snapdragon X55
FREQUENCY BAND
- Sub-6G : n1, n2, n3, n5, n7, n8, n12, n20, n28, n38, n40, n41, n66, n71, n77, n78, n79
- LTE-FDD : B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71
- LTE-TDD : B34, B38, B39, B40, B41, B42, B43, B48
- WCDMA : B1, B2, B3, B4, B5, B8
- GNSS : GPS, GLONASS, Beidou, Galileo, and QZSS
DATA RATE
- Sub-6G : 2.4 Gbps (DL) / 500 Mbps (UL)
- LTE : 1 Gbps (DL) / 200 Mbps (UL)
- HSPA+ : 42 Mbps (DL) / 5.76 Mbps (UL)
SOFTWARE FUNCTIONS
- Operating systems : Windows/Linux/Android
- Communication protocols : TCP/IP, IPV4, IPV6, Multi-PDP, FTP, FTPS, HTTP, HTTPS, MQTTS, DNS, SSL3.0
- Dial Up : RNDIS、NDIS、PPP、MBIM
- SMS : Supports MT, MO, CB, Text, PDU
- Firmware upgrade : Supports firmware upgrade via USB port
HARDWARE SPECIFICATIONS
- SIM Card : 1.8V/2.95V
- Antenna : For 3G/4G/5G/GNSS 6 × IPEX-4 connectors 4 × IPEX-4 connectors
- Power Supply : 3.135~4.4V
- Form Factor : M.2
- Dimensions : 52.0 × 30.0 × 2.3 mm 42.0 × 30.0 × 2.3 mm
- Operating Temperature : -30℃ ~ +70℃
