RM520N-GL 5G/4G/3G Module Designed For Jetson Nano, Multi Mode Multi Band
This 5G/4G/3G Jetson Nano communication module provides options for SIMCom 5G module SIM8202G-M2 and Quectel 5G module RM520N-GL, supports 5G NSA and SA networking.
The base board features standard M2 connector, allows connecting with different 4G or 5G communication module in M2 package. There are also onboard interfaces like USB3.1 port, audio jack, SIM card slot, etc. Combined with our configuration script and development resources, it is easy to enable 5G high speed communication for the Jetson Nano or computer. This 5G module is ideal for fast evaluating 5G modules, as well as being integrated into sorts of applications where 5G connection is required.
User Manual / Datasheet / Example Codes Etc.
Features
- Standard 40PIN GPIO extension header, supports direct attaching to Jetson Nano.
- RM520N-GL core module, with multi mode multi band support.
- 5G/4G/3G communication, supports functions like phone calls, SMS, cloud communication, etc.
- USB 3.1 port for testing AT commands, sending messages, cloud communication, making phone calls, getting GNSS positioning data, etc.
- SIM card slot supports 1.8V / 3V SIM card.
- 2x LED indicators, easy to monitor the working status.
- AT command support, based on 3GPP TS 27.007, 27.005, and V.25TER command set.
- Onboard audio jack and audio decoder, allow audio operation like making phone calls.
- Multi-constellation dual-band positioning: GPS, GLONASS, Beidou, Galileo, and QZSS.
- Operating system support: Windows/Linux/Androi
Specifications
Frequency band
- Sub-6G : n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79
- LTE-FDD : B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71
- LTE-TDD : B34, B38, B39, B40, B41, B42, B43, B48
- WCDMA : B1, B2, B4, B5, B8, B19
- GNSS : GPS, GLONASS, Beidou, Galileo, and QZSS
Data rate
- Sub-6G : SA: 2.4 Gbps (DL) / 900 Mbps (UL) / NSA: 3.4 Gbps (DL) / 550 Mbps (UL)
- LTE : 1.6 Gbps (DL) / 200 Mbps (UL)
- HSPA : 42 Mbps (DL) / 5.76 Mbps (UL)
Hardware info
- SIM card : 1.8V/3.0V
- Power supply : 5V 3A
- Antenna connector : 4x IPEX-4 connector
- Module dimensions : 52.0×30.0×2.3mm
Application
- Applicable regions : Global
- Application examples : CPE, Smart gateway, Drone, Live streaming, Remote medical treatment, Intelligent security
5G/4G/3G MODULE FOR JETSON NANO
Supports 5G/4G/3G, Supports 5G SA And NSA, Multi Mode Multi Band, Applicable For Regions With 5G Sub-6G Signal Coverage
Package Includes
Cloud Communication
Supported Communication Protocols: TCP / IP / IPV4 / IPV6 / Multi-PDP / FTP / FTPS / HTTP / HTTPS / MQTTS / DNS / SSL3.0
High-Precision GNSS Support
Supports GPS, Beidou, Glonass, Galileo, QZSS, LBS
Appearance & Introduction
Dimensions
What's On Board
1. M.2 connector
- compatible with SIM8200EA-M2, SIM8202G-M2 and RM520N-GL modules
2. USB3.1 port
- for connecting with computer or Jetson Nano
3. 3.5mm headphone/microphone jack
4. 40PIN GPIO header
- for connecting with Jetson Nano
5. Fan header
- for 5V cooling fan
6. nano SIM card slot
- supports 1.8V / 3V SIM card
7. 5V 3A power input
8. Network indicator
9. Power indicator
10. Reset
11. Power switch
12. Power supply circuit
13. Audio drive circuit
14. Power supply selection jumper
- 5V - SYS: powered by Jetson Nano 40PIN GPIO
- 5V - USB: powered by external 5V 3A power adapter
15. Module on/off control pin enable jumper
- PWR - D5: enabled by default, Jetson Nano D5 pin can be used to turn on/off the module
- RST - D6: enabled by default, Jetson Nano D6 pin can be used to reset the module
- MIC+/MIC-: for external microphone
- SPK+/SPK-: for external speaker
