CAN bus Module (B) for Raspberry Pi Pico, enabling long range communication through SPI
₹​1,397.12
₹​1,184.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 12
B2B GST Credit Available
Price in reward points: 1184

This is a CAN Bus Module (B) For Pico Enabling Reliable Long Range Communication For Raspberry Pi Pico With Other Devices and Comes with online development resources and manual.


Features

  • Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series boards
  • Features CAN function, adopts SPI interface CAN controller MCP2515 with transceiver SIT65HVD230DR
  • Comes with online development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)


Resources

User Guide


Specifications

OPERATING VOLTAGE3.3V~5V
CAN CONTROLLERMCP2515
CAN TRANSCEIVERSIT65HVD230DR
COMMUNICATION BUSSPI
BAUDRATE5K~1000Kbps


Onboard Peripherals


  1. RT9013-33GB
    500mA low dropout, low noise, ultra-fast LDO
  2. MCP2515
    Second generation standalone CAN controller
  3. SIT65HVD230DR
    3.3V CAN transceiver
  1. Terminal resistor selection
    ON: connected to 120R matching resistor
    OFF: disconnected from 120R matching resistor
  2. CAN bus terminal
