Name: Sipeed M1S Dock AI With 1.69 Inch Touch Display Wifi-Bluetooth Module
Brand: Sipeed
SKU: 04392
Price: 2655.00 INR
Availability: OutOfStock

Sipeed M1S Dock AI With 1.69 Inch Touch Display Wifi-Bluetooth Module

Sipeed

Sipeed M1S Dock AI With 1.69 Inch Touch Display Wifi-Bluetooth Module

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹2,655.00

₹2,250.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 22
B2B GST Credit Available

Price in reward points: 2250

Stock: 0 in Stock
SKU: 04392
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Sipeed M1S Dock AI With 1.69 Inch Touch Display Wifi-Bluetooth Module

Sipeed M1s Dock is a development board designed based on Sipeed BL808 M1s Module that supports 2.4G WIFI/BT/Bluetooth5 and is equipped with a base of the screen and base of the MIPI camera. Designed with the most minimal design, for customers to evaluate the module, or hobbyists to play directly, etc.

BL808 mainly includes two subsystems, wireless and multimedia. The wireless subsystem includes a RISC-V 32-bit high-performance CPU, integrated Wi-Fi /BT/Bluetooth5 wireless subsystem, which can provide a variety of connection and transmission experiences. The multimedia subsystem includes a RISC-V 64-bit ultra-high-performance CPU and integrates video processing modules such as DVP/CSI/ H264/NPU, which can be widely used in various AI fields such as video surveillance/smart speakers. As well as the BLAI-100 (Bouffalo Lab AI engine) NPU for video/audio detection and/or recognition.

Technical Datasheet

Features

Stronger-performance CPU: main chip BL808 RISC-V + NPU BLAI-100, the highest operating frequency of 480MHz to achieve the powerful performance of three-core heterogeneous.
Wireless three-mode integration: Support 2.4G WIFI / BT / Bluetooth5, any mode can efficiently be networked.
One-click easy Burning: Sipeed M1s Dock has an onboard USB-to-UART debugger, which can realize one-click burning without pressing physical buttons.
Friendly visualization features: The onboard display interface (optional 1.69-inch 240x280 capacitive touch screen) and the MIPI camera interface(optional 200W pixel camera) provide a stronger visual experience.
High port compatibility: Route USB-OTG to USB Type-C port.

Applications

artificial intelligence application
face recognition
posture recognition
gesture recognition
video surveillance

Pin Diagram
