VisionFive2 RISC-V Single Board Computer 4GB WiFi, StarFive JH7110 Processor with Integrated 3D GPU, base on Linux, Without Wifi Module and Supply

VisionFive2 RISC-V Single Board Computer 4GB WiFi, StarFive JH7110 Processor with Integrated 3D GPU, base on Linux, Without Wifi Module and Supply

This is an VisionFive2 RISC-V Single Board Computer 4GB WiFi, StarFive JH7110 Processor with Integrated 3D GPU, base on Linux Without Wifi Module and Supply . Onboard RV64GC ISA Quad-core 64-bit SoC, operating frequency up to 1.5GHz, VisionFive 2 supports OpenCL 3.0, OpenGL ES 3.2, and Vulkan 1.2. It is available in 4GB/8GB LPDDR4 RAM options and an optional wireless module. Also, it has multiple onboard interfaces, including M.2 / CSI / DSI / HDMI / eMMC / USB 3.0 / 40PIN GPIO / RJ45 Gigabit Ethernet port / TF card slot, etc. Supports 4K@60fps and H264/H265 multi-stream video decoding, 1080p@30fps and H265 multi-stream video encoding. Onboard 40PIN GPIO header, VisionFive2 is compatible with Raspberry Pi series boards. Provides wide software compatibility including support for Debian.

User Manual / Datasheet / Example Codes Etc.

Features

• Onboard RV64GC ISA Quad-core 64-bit SoC, operating frequency up to 1.5GHz
• Supports OpenCL 3.0, OpenGL ES 3.2 and Vulkan 1.2
• Available in 4GB/8GB LPDDR4 RAM options, and optional wireless module
• Multiple onboard interfaces, including M.2 / CSI / DSI / HDMI / eMMC / USB 3.0 / 40PIN GPIO / RJ45 Gigabit Ethernet port / TF card slot, etc
• Supports 4K@60fps and H264/H265 multi-stream video decoding, 1080p@30fps and H265 multi-stream video encoding
• Onboard 40PIN GPIO header, compatible with the pinout of Raspberry Pi series boards
• Provides wide software compatibility including support for Debian

Specifications

Package Includes

40PIN GPIO Header

Onboard Resources

1. JH7110
2. PoE port
3. Boot mode selection
4. 40Pin GPIO
5. 4GB/8GB LPDDR4 SDRAM
6. Reboot button
7. EEPROM
8. Type-C power port
9. 2-lane MIPI CSI
10. PMIC
11. 2PIN FAN header
12. Gigabit Ethernet Chip
13. Gigabit Ethernet port (with PoE function)
14. Gigabit Ethernet port
15. HDMI 2.0 port
16. 3.5mm Audio Jack
17. USB 3.0 Ports
18. 4-lane MIPI DSI
19. USB 3.0 Host chip
20. 2-lane MIPI DSI
21. eMMC socket
22. TF card slot
23. QSPI Flash
24. M.2 M-Key


Dimensions
