VisionFive2 RISC-V Single Board Computer 8GB WiFi, StarFive JH7110 Processor with Integrated 3D GPU, base on Linux - With WiFi Module

VisionFive2 RISC-V Single Board Computer 8GB WiFi, StarFive JH7110 Processor with Integrated 3D GPU, base on Linux - With WiFi Module

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹14,092.74

₹11,943.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 119
B2B GST Credit Available

Price in reward points: 11943

Stock: 0 in Stock
SKU: 23874
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Onboard RV64GC ISA Quad-core 64-bit SoC, operating frequency up to 1.5GHz, VisionFive 2 supports OpenCL 3.0, OpenGL ES 3.2, and Vulkan 1.2. It is available in 8GB LPDDR4 RAM options and an optional wireless module. Also, it has multiple onboard interfaces, including M.2 / CSI / DSI / HDMI / eMMC / USB 3.0 / 40PIN GPIO / RJ45 Gigabit Ethernet port / TF card slot, etc. Supports 4K@60fps and H264/H265 multi-stream video decoding, 1080p@30fps and H265 multi-stream video encoding. Onboard 40PIN GPIO header, VisionFive2 is compatible with Raspberry Pi series boards. Provides wide software compatibility including support for Debian.

Features

Onboard RV64GC ISA Quad-core 64-bit SoC, operating frequency up to 1.5GHz
Supports OpenCL 3.0, OpenGL ES 3.2 and Vulkan 1.2
8GB LPDDR4 RAM wireless module
Multiple onboard interfaces, including M.2 / CSI / DSI / HDMI / eMMC / USB 3.0 / 40PIN GPIO / RJ45 Gigabit Ethernet port / TF card slot, etc
Supports 4K@60fps and H264/H265 multi-stream video decoding, 1080p@30fps and H265 multi-stream video encoding
Onboard 40PIN GPIO header, compatible with Raspberry Pi series boards
Provides wide software compatibility including support for Debian

Resources

User Manual

Specifications

PROCESSOR	StarFive JH7110
CPU	RISC-V U74 Quad-core 64-bit RV64GC ISA SoC With 2MB L2 cache and S7 core, operating frequency up to 1.5GHz
GPU	IMG BXE-4-32 MC1, operating frequency up to 600MHz
MEMORY	8G Byte LPDDR4
STORAGE	TF card (Not included)
CAMERA	MIPI CSI 2lane 1080p@30fps
DISPLAY	1 × 2-lane MIPI DSI 1080p@30fps 1 × 4-lane MIPI DSI 2K@30fps (Only one DSI port can be used for display at the same time) 1 × HDMI 2.0 4K@30fps, 2K@60fps
USB HOST	4 × USB 3.0 Type-A port
USB DEVICE	1 × USB Device (multiplexed with the USB Type-C port)
NETWORKING	1 × Gigabit Ethernet port (main Ethernet port) 1 × 100/10M Ethernet port
RESET BUTTON	Press the reset button to reboot when in the U-boot mode; Press and hold the reset button for three seconds to reboot after the system boots
BOOT MODE SWITCH	RGPIO_1	RGPIO_0	Boot Mode
	0	0	flash
	0	1	TF Card
	1	0	eMMC
	1	1	UART
DEBUG PIN HEADERS	Multiplex pin 8 and pin 10 (physical address) on the 40PIN header, for UART TX and UART RX functions
USB TYPE-C POWER PORT	Supports Quick Charge input 5V DC (minimum 3A) (up to 30 W) Supports 5~20V fixed voltage input Supports USB Type-C PD 2.0, 9V/2A, 12V/2A, 15V/2A, 20V/2A Supports QC 3.0/2.0 adapter, 9V/2A, 12V/1.5A
OTHER POWER SUPPLY	5V input via 40PIN GPIO header PoE port power input, requires external PoE module
OTHER INTERFACES	40PIN GPIO M.2 M-Key Solid State Drive socket eMMC socket 2PIN Fan header 3.5mm Audio Jack, 4-pole stereo audio jack
DIMENSIONS	100 × 74 × 21mm
COMPLIANCE	RoHS, FCC, CE
RECOMMENDED OPERATING AMBIENT TEMPERATURE	0~50℃ (If the operating temperature of the chip exceeds 85°C, the frequency and voltage of the CPU will be automatically reduced for cooling)

Onboard Resources

JH7110
PoE port
Boot mode selection
40Pin GPIO
8GB LPDDR4 SDRAM
Reboot button
EEPROM
Type-C power port
2-lane MIPI CSI
PMIC
2PIN FAN header
Gigabit Ethernet Chip

Gigabit Ethernet port (main Ethernet port)
100/10M Ethernet port
HDMI 2.0 port
3.5mm Audio Jack
USB 3.0 Ports
4-lane MIPI DSI
USB 3.0 Host chip
2-lane MIPI DSI
eMMC socket
TF card slot
QSPI Flash
M.2 M-Key
