Name: WIZnet W5500 Ethernet Controller IC TCP/IP+MAC+PHY - LQFP-48
Brand: WIZNET
SKU: 05340
Price: 216.00 INR
Availability: InStock

WIZnet W5500 Ethernet Controller IC TCP/IP+MAC+PHY - LQFP-48

WIZNET

WIZnet W5500 Ethernet Controller IC TCP/IP+MAC+PHY - LQFP-48

Based on 0 reviews. - Write a review

₹216.00

₹183.05 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 2
B2B GST Credit Available

Price in reward points: 183

Stock: 223 in Stock
SKU: 05340
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

WIZnet W5500 Ethernet Controller IC TCP/IP+MAC+PHY - LQFP-48

Datasheet

The W5500 chip is a Hardwired TCP/IP embedded Ethernet controller that provides easier Internet connection to embedded systems. W5500 enables users to have the Internet connectivity in their applications just by using the single chip in which TCP/IP stack, 10/100 Ethernet MAC and PHY embedded.

WIZnet‘s Hardwired TCP/IP is the market-proven technology that supports TCP, UDP, IPv4, ICMP, ARP, IGMP, and PPPoE protocols. W5500 embeds the 32Kbyte internal memory buffer for the Ethernet packet processing. If you use W5500, you can implement the Ethernet application just by adding the simple socket program. It’s faster and easier way rather than using any other Embedded Ethernet solution. Users can use 8 independent hardware sockets simultaneously

SPI (Serial Peripheral Interface) is provided for easy integration with the external MCU. The W5500’s SPI supports 80 MHz speed and new efficient SPI protocol for the high speed network communication. In order to reduce power consumption of the system, W5500 provides WOL (Wake on LAN) and power down mode
