WIN-IO-4AOMC IO Module With 12-bit, 4 Analog Output 4-20mA and Modubus RTU

The WIN-IO-4AOMC IO Module is a specialized industrial automation solution designed to cater to precise analog output requirements in diverse applications. Boasting 4 Analog Output channels and Modbus RTU communication capability, this module offers a reliable and efficient means of controlling analog signals in your industrial processes.

The IO modules communicate via RS485. The port can drive distances up to max 700 meters without the use of any repeater (this feature however also depends on the signal strength of the Modbus Master Device).

The RS485 Digital IO module is sturdy, low power usage and easy to use.

Datasheet

Specifications

I/O Connectors : 2 Pin 5.08 mm pitch pluggable screw Terminal Block
Dimensions : 60 mm L x 110 mm B x 50 mm H
Power : Input Power – 12 – 24 VDC or 24 V AC/DC Typical – 12V DC @ 80mA
Operating Temperature : 0 – 60°C (32 ~ 140°F)
Storage Temperature : -20 - 0°C (-4 ~ 158°F)
Storage Humidity : 5 ~ 95 % RH, non – Condensing

AO Outputs

Channels : 4
Inputs Resolution 12 Bit
Signal Range : 4 – 20 mA
Accuracy : ±2 % of Full scale
Linearity Error : 0.1 %
Conversion Time : 20 mse

Additional Features

All inputs and communication port isolated
Input power reverse polarity safety
ESD Safety IEC 61000-4-2, ±30KV contact, ±30KV air
EFT IEC 61000-4-4, 50A (5/50ms)
750V isolation
CRC Error check
No configuration needed on the IO board
1 year comprehensive warranty
