Photo Interrupter Sensor, Robot Speed Measuring Module

Photo Interrupter Sensor is a light occlusion interrupt sensor, which is often used in smart car speed measurement.

Principle: This product adopts a WYC-H206 slot photoelectric sensor, one end is an infrared transmitting tube, and the other end is an infrared receiving. When there is a block, the infrared receiving end cannot receive infrared and outputs a high level, which is triggered by inverting Schmitt. The device becomes low-level output, and the signal lamp is on at the same time. The use of the Schmitt trigger makes the output signal more stable, with good waveform and no jitter.

User Manual / Datasheet / Example Codes Etc.

Features

Infrared detection, eliminating the interferences of external stray light
Schmitt trigger, stable wave form and signals
Signal output indicator (while breaking the beam, outputs low level, the indicator lights up)

Specifications

Power: 3.3V ~ 5V
Dimension: 26.8mm × 15mm × 18.7mm
Mounting holes size: 3mm
Gap width: 6mm

Applications

Motor speed detection
Pulse counter

Package Includes

1x Photo Interrupter Sensor
1x 20-slots encoder disk
1x XH2.54 3PIN wire

How to Use

In the case of working with a MCU:

VCC ↔ 3.3V ~ 5V
GND ↔ GND
DOUT ↔ MCU.IO (digital output)

Dimensions
