2.66inch E-Paper E-Ink Display Module (B) For Raspberry Pi Pico, 296×152 Pixels, Red / Black / White, SPI Interface

2.66inch EPD (Electronic Paper Display) Module For Raspberry Pi Pico, 296 × 152 Pixels, Black / White /Red, SPI Interface.

This display is an Active Matrix Electrophoretic Display (AM EPD), with interface and a reference system design. The display is capable to display images at 1-bit white, black and red full display capabilities. The 2.66 inch active area contains 296×152 pixels. The module is a TFT-array driving electrophoresis display, with integrated circuits including gate driver, source driver, MCU interface, timing controller, oscillator, DC-DC, SRAM, LUT, VCOM. Module can be used in portable electronic devices, such as Electronic Shelf Label (ESL) System.

User Manual / Datasheet / Example Codes Etc.

Features

2.66inch EPD (Electronic Paper Display) Module For Raspberry Pi Pico, 296 × 152 Pixels, Black / White /Red, SPI Interface.
No backlight keeps displaying the latest content for a long time even when powered down.
Ultra-low power consumption, basically power is only required for refreshing.
SPI interface requires minimal IO pins.

Specifications

Size: 2.66 inch
Outline dimensions (screen only): 71.820mm × 36.304mm × 1.00mm
Outline dimensions (driver board): 74.0mm × 37.00mm
Display size: 60.088mm × 30.704mm
Operating voltage: 3.3V
Communication interface: SPI
Pixel pitch: 0.202 × 0.203
Resolution: 296 × 152
Display color: Red, Black, White
Greyscale: 2
Full refresh: 15s
Refresh power: 42.4mW (typ.)
Sleep current: <0.01uA (almost 0)

Package Includes

1x Pico-ePaper-2.66-B
1x Standoff pack

Raspberry Pi Pico Header Compatibility

Pinout Definition

Dimensions
