2.9inch E-Paper E-Ink Display Module For Raspberry Pi Pico, 296×128 Pixels, Black / White, SPI Interface

2.9inch EPD (Electronic Paper Display) Module For Raspberry Pi Pico, 296 × 128 Pixels, Black / White, SPI Interface.

This display is an Active Matrix Electrophoretic Display (AMEPD), with interface and a reference system design. The 2.9” active area contains 296x128 pixels, and has 1- bit B/W full display capabilities. An integrated circuit contains gate buffer, source buffer, interface, timing control logic, oscillator, DC-DC. SRAM.LUT, VCOM and border are supplied with each panel.

User Manual / Datasheet / Example Codes Etc.

Features

No backlight, keeps displaying last content for a long time even when power down
Ultra low power consumption, basically power is only required for refreshing
SPI interface, requires minimal IO pins
Onboard voltage translator, compatible with 3.3V / 5V MCUs
Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)

Specifications

Dimension: 2.9inch
Outline dimensions (raw panel): 79.0mm × 36.7mm × 1.05mm
Outline dimension(with driver board): 82.0mm × 38.0mm
Display size: 66.89mm × 29.05mm
Operating voltage: 3.3V
Interface: SPI
Dot pitch: 0.227 × 0.226
Resolution: 296 × 128 pixels
Display color: Black, White
Greyscale: 4
Partial refresh time: 0.6s
full refresh time: 3s
Refresh power: 26.4mW (typ.)
Standby current: <0.01uA (almost none)
Touch points: 5 (MAX)
Touch type: Capacitive
Touch interface: I2C (Address: 0x48)
Touch panel: Toughened glass panel

Package Includes

1x Pico-ePaper-2.9
1x PH2.0 8PIN wire 20cm
1x Standoff pack

Raspberry Pi Pico Header Compatibility

Onboard Voltage Translator

Pinout Definition

Dimensions
