2.9inch E-Paper E-Ink Display Module (B), 296×128, Red / Black / White, SPI Interface

2.9inch E-Paper E-Ink Display Module (B), 296×128, Red / Black / White, SPI Interface

This is an 2.9inch E-Paper E-Ink Display Module (B). The 2.9inch E-paper display comes with 296×128 pixels Resolution, >170° View angle & display color Red, Black, White, Which support 3-wire SPI, 4-wire SPI interface for connecting with controller boards like Raspberry Pi, Jetson Nano, Arduino, STM32 etc.

User Manual / Datasheet / Example Codes Etc.

Features

• No backlight, keeps displaying last content for a long time even when power down
• Ultra low power consumption, basically power is only required for refreshing
• SPI interface, for connecting with controller boards like Raspberry Pi/Jetson Nano/Arduino/STM32, etc.
• Onboard voltage translator, compatible with 3.3V / 5V MCUs
• Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32)

Specifications

• OPERATING VOLTAGE : 3.3V/5V
• DISPLAY COLOR : red, black, white
• RESOLUTION : 296×128 pixels
• VIEWING ANGLE : >170°
• INTERFACE : 3-wire SPI, 4-wire SPI
• GREY SCALE : 2
• OUTLINE DIMENSIONS : 89.5 × 38mm
• FULL REFRESH TIME : 15s
• DISPLAY SIZE : 66.90 × 29.06mm
• REFRESH POWER : 30mW(typ.)
• DOT PITCH : 0.227 × 0.226mm
• STANDBY CURRENT : <0.01uA (almost none)

Package Includes

• 1x 2.9inch e-Paper Module
• 1x PH2.0 20cm 8Pin

Onboard SPI Control Interface

For Connecting With Controller Boards Like Raspberry Pi/Jetson Nano/Arduino/STM32

• VCC : 3.3V/5V
• GND : Ground
• DIN : SPI MOSI pin
• CLK : SPI SCK pin
• CS : SPI chip selection, low active
• DC : Data / Command selection (high for data, low for command)
• RST : External reset, low active
• BUSY : Busy status output, low active

Onboard Voltage Translator

Compatible With 3.3V / 5V MCUs

Dimensions
