STM32F411E-DISCO Discovery kit with STM32F411VE MCU Development Board, On-Board ST-LINK/V2, MEMS Sensors, Eight LED's

The STM32F411E-DISCO is a discovery kit for STM32F411 line MCU. The STM32F411 discovery kit is a low cost and easy to use development kit to quickly evaluate and start development with an STM32F4 microcontroller. It is based on an STM32F411VET6 microcontroller and includes an ST-LINK/V2 embedded debug tool interface, ST MEMS gyroscope, ST MEMS accelerometer plus magnetometer, ST MEMS digital microphone, audio DAC with integrated class D speaker driver, LED's, pushbuttons and a USB OTG micro AB connector.

Features

• STM32F411VET6 ARM 32bit Cortex-M4 CPU with FPU
• Onboard ST-LINK/V2 with selection mode switch to use the kit as a standalone STLINK/V2
• Power supply through USB bus or from an external 5 V supply voltage
• L3GD20 ST MEMS motion sensor, 3 axis digital output gyroscope
• LSM303DLHC ST MEMS featuring 3D digital linear acceleration sensor & 3D digital magnetic sensor
• MP45DT02 ST MEMS audio sensor, omnidirectional digital microphone
• CS43L22 audio DAC with integrated class D speaker driver
• Extension header for LQFP48 I/Os for a quick connection to the prototyping board and easy probing

Resources
Technical Datasheet

Applications

Motor Drive & Control, Medical, Industrial, Consumer Electronics, Portable Devices
