AM11-12W05V 5V 12W AC to DC Step Down Power Supply Module

AM11-12W05V is a low-power AC-DC step-down power supply module with an input voltage of 85~264Vac/100~370Vdc. This series of products are widely used consumer electronics, industrial control equipment, instrumentation, smart home and so on for its advantages such as ultra-low ripple, ultra-low power consumption, high efficiency, safe isolation and high reliability. The user does not need to consider stability because the output can be stabilized even in a complex voltage environment.

Datasheet

Features

Ultra-low ripple: full load ripple is less than 100mV
Ultra-small size: 38.2*25.2*23mm
Input voltage: universal voltage of 85 ~ 264Vac/100~370Vdc
Protection measures: over-voltage protection, over-current protection, short-circuit protection, over-temperature protection
High-quality scheme: greatly improve its work efficiency, with a maximum efficiency of 86.2%
AM11 series is aimed at economical ultra-low cost

Specifications

Input voltage: 100~250V
Output voltage: 5V
Output current: 2400mA
Output Power: 12W
Working frequency: 50/60 Hz
Working Temperature: -40 to 85°C
Size: 38.2*25.2*23mm
Package: DIP

Application Scenarios

Power Supply System of Charging Pile
Intelligent home and Industrial sensors, etc.
Internal power supply system of security alarm
Industrial control
MCU motherboard, toys
Supply LED driving Lamp belt with Power
Intelligent street lamp
Intelligent switch, socket
