Beitian Dual BN-220 GPS GLONASS Antenna Module TTL Level RC Drone
This is a Beitian Dual BN-220 GPS GLONASS Antenna Module. The Beitian Dual BN-220 GPS module comes with 8030-KT chipset. This BN-220 GPS Module can show your speed. When you use it for Raspberry Pi, there is no driver needed. The data output when the TX LED flashing in blue; PPS LED not bright when GPS not fixed, flashing in red when fixed.
Specifications
- Electrical Characteristics
- Chipset : 8030-KT
- Receiving Format : GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
- Frequency : GPS L1,GLONASS L1,BeiDou B1,SBAS L1,Galileo
- Channels : 72 Searching Channel
Sensitivity
- Tracking : -167dBm
- Reacquisition : -160dBm
- Cold start : -148dBm
- Hot start : -156dBm
Accuracy
- Position Horizontal : 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky)
- Rate : 0.1m/sec 95% (SA off)
- Timing : 1us synchronized to GPS time
- Acquisition Time
- Cold Start : 26s
- Warm start : 25s
- Hot start : 1s
Data and Update Rate
- Support Rate : 4800bps to 921600bps,Default 9600bps
- Data Level : TTL or RS-232,Default TTL level
- Data Protocol : NMEA-0183 or UBX, Default NMEA-0183
- Single GNSS : 1Hz-18Hz
- Concurrent GNSS : 1Hz-10Hz,Default 1Hz
- Operational Limits
- Altitude : 50,000m Max
- Rate : 515m/s Max
- Acceleration : Less than 4g
Power consumption
- VCC : DC Voltage 3.0V-5.5V,Typical: 5.0V
- Current : Capture 50mA/5.0V
- Operating temp : -40 °C ~ +85°C
- Storage Temp : -40°C ~ +105°C
Indicator
- TX LED:blue.The data output, TX LED flashing
- PPS LED:red.PPS LED not bright when GPS not fixed,flashing when fixed
Wiring
- GND,TX output,RX input,VCC(3.0v-5.5v)
