Dual ETH Mini-Computer For Raspberry Pi Compute Module 4 (NOT Included), Gigabit Ethernet, 4CH Isolated RS485, USB2.0

This is an CM4-ETH-RS485-BASE-B, which is an expansion board that can be used with Raspberry Pi Compute Module 4, and supports a 7-36V DC power supply and 5V DC power supply of Type-C interface. Onboard four isolated RS485 interfaces, 100M+1000M dual network ports, HDMI interface, two CSI interfaces, two USB interfaces, etc.

User Manual / Datasheet / Example Codes etc.

Specifications

CM4 SOCKET : suitable for all variants of Compute Module 4
NETWORKING : Gigabit Ethernet RJ45 connector, 100M Ethernet RJ45 connector
USB : USB 2.0 Type A × 2
CONNECTOR : Isolated RS485 × 4, Power screw terminal × 1
CAMERA : MIPI CSI-2 port × 2 (15pin 1.0mm FPC connector)
VIDEO : HDMI port × 1, supports 4K 30fps output
RTC : Real-time clock with battery socket and ability to wake Compute Module 4
STORAGE : MicroSD card socket for Compute Module 4 Lite (without eMMC) variants
FAN HEADER : allows speed adjustment, 5V
INDICATOR : Power indicator × 1, CM4 status indicator × 1, User LED × 2, RS485 communication indicator × 8
POWER INPUT : 7-36V
DIMENSIONS : 123 × 98 × 32mm

Waveshare Dual ETH Quad RS485 Expansion Board Inside

Package Includes

CM4-ETH-RS485-BASE-B x1
Metal case (top and bottom) x1
Fan x1
12V 2A Power Supply x1
Screwdriver x1
Antenna connector rubber plug x1
Screws pack x1
