Mini Base Board (A) Designed for Raspberry Pi Compute Module 4
₹​1,871.48
₹​1,586.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 16
B2B GST Credit Available

This is a Mini Base Board For Compute Module 4 and is suitable for evaluating the raspberry pi cm4 or Being Integrated Into End Products. This base board comes with Powerful functions in a credit card sized body.



Resources

User Guide


Specifications

CM4 SOCKETsuitable for all variants of Compute Module 4
NETWORKINGGigabit Ethernet RJ45 connector
M.2 M KEY, supports communication modules or NVME SSD
CONNECTORRaspberry Pi 40PIN GPIO header
USBUSB 2.0 Type A × 2, USB 2.0 via FFC connector × 2
DISPLAYMIPI DSI display port (15pin 1.0mm FPC connector)
CAMERAMIPI CSI-2 camera port × 2 (15pin 1.0mm FPC connector)
VIDEOHDMI port × 2 (including one port via FFC connector), supports 4K 30fps output
RTCN/A
STORAGEMicroSD card socket for Compute Module 4 Lite (without eMMC) variants
FAN HEADERno fan control, 5V
POWER INPUT5V
DIMENSIONS85 × 56mm


Onboard Peripherals


  1. CM4 socket
    suitable for all variants of Compute Module 4
  2. Power input/Programming
    5V/2.5A power supply, or used for eMMC burning
  3. DISP
    MIPI DSI display port
  4. FAN
    for connecting cooling fan, allows speed adjustment and measurement
  5. CAM
    2x MIPI CSI camera ports
  6. HDMI0 connector
    HDMI0 port, supports 4K 30fps output
  7. USB 2.0 ports
    2x USB 2.0 ports, for connecting sorts of USB devices
  8. Gigabit Ethernet connector
    Gigabit Ethernet RJ45 connector, with 10 / 100 / 1000M network support
  9. M.2 indicator
    indicating the operating status of M.2 interface
  10. ACT indicator
    indicating the operating status of Raspberry Pi
  11. PWR indicator
    indicating the status of Raspberry Pi power supply
  12. BOOT selection
    ON: CM4 would be booted from USB-C interface
    OFF: CM4 would be booted from eMMC or Micro SD card
  1. 40PIN GPIO header
  2. Micro SD card slot
    for connecting a Micro SD card with pre-burnt image (Lite variant ONLY)
  3. HDMI1 FFC connector
    HDMI1 port, supports 4K 30fps output
  4. USB 2.0 FFC connector
    can be connected through an adapter
  5. FE1.1S
    USB HUB chip, expanding one USB port to 4x ports
  6. M.2 slot
    supports sorts of NVME SSD, or communication modules with PCIE M.2 KEY-M interface
