₹5,382.00
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 47
B2B GST Credit Available
Price in reward points: 4745
- Stock: 0 in Stock
- SKU: 05636
- Delivery Time
- Bulk & B2B RFQ
Dwin 10.1 Inch Cheap HMI LCD, Resistive Touch, IPS TFT 1024x600 250nit UART LCM LCD Display With Enclosure DMG10600C101_15WTR (Commercial Grade)
This model is the intelligent LCD display module with a Resistive touch screen for user interactivity. It has onboard serial UART PORT which can be controlled by any microcontroller via a simple yet powerful command set. It can be used as TFT Display & Touch controller in various electronic equipment such as vending machines, currency counting machines, washing machines, and many other similar appliances.
Features
- Based on self-designed T5L2 ASIC, 16.7M Color, 24bit, 1024*600 Pixel;
- Resistive touch screen;
- RS232&RS485 Interface,8Pin3.81mm socket;
- Download via SD card or on-line serial port;
- Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required;
- Dual Development System: DGUS II/ TA(Instruction set);
- Wide viewing angle, 85°/85°/85°/85° (L/R/U/D)
- With GUI & OS dual-core, GUI with rich controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51.
Specifications
- LCD Type : IPS, TFT LCD
- Viewing Angle : Wide viewing angle, 85°/85°/85°/85°(L/R/U/D)
- Resolution : 1024×600 pixels (support 0°/90°/180°/270°)
- Color : 24-bit 8R8G8B
- Active Area (A.A.) : 223.2mm (W)×125.8mm (H)
- Backlight Mode : LED
- Backlight Service Life : >20000 hours (Time of the brightness decaying to 50% on the condition of continuous working with the maximum brightness)
- Brightness : DMG10600C101_15WTR: 250nit
- Brightness Control : 0~100 grade (When the brightness is adjusted to 1%~30% of the maximum brightness, flickering may occur and is not recommended to use in this range)
Touch Parameters
- Type : RTP (Resistive touch panel)
- Structure : ITO film + ITO glass
- Touch Mode : Support point touch and drag
- Surface Hardness : 3H
- Light Transmittance : Over 80%
- Life : Over 1,000,000 times touch
Operating environment
- Operating Temperature : -20℃~70℃ (12V @ 60% RH)
- Storage Temperature : -30℃~80℃
- Operating Humidity : 10%~90%RH, typical value of 60% RH
- Conformal Coating : None
