DWIN 9.7 Inch HMI TFT LCD, Capacitive Touch, TN TFT 1024x768 270nit LCD Display, DMG10768C097_03WTC (Commercial grade)
₹​8,102.00
₹​6,866.10 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 69
B2B GST Credit Available
Price in reward points: 6866

DWIN 9.7 Inch HMI TFT LCD, Capacitive Touch, TN TFT 1024x768 270nit LCD Display, DMG10768C097_03WTC (Commercial grade)

This model is the intelligent LCD display module with a Capacitive touch screen for user interactivity.  It has onboard serial UART PORT which can be controlled by any microcontroller via a  simple yet powerful command set. It can be used as TFT Display & Touch controller in various electronic equipment such as vending machines, currency counting machines, washing machines, and many other similar appliances.


Datasheet


Features

  • Based on T5L ASIC 9.7 Inches, 1024xRGBx768, 16.7M Colors, Cost-Effective screen
  • UART2: ON=TTL/CMOS; OFF=RS232; 8Pin_2.0mm FCC Socket
  • Download via SD card or on-line serial port
  • Easy-to-use DWIN DGUS V7.6 GUIs Development.no coding skills required
  • Dual Development System:DGUSⅡ/TA(Instruction set)
  • TN View Angle: 70°/70°/50°/70° (L/R/U/D)
  • With GUI & OS dual-core, GUI with rich controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51


Specifictions


Display

  • Color : 24-bit 8R8G8B
  • LCD Type : TN, TFT LCD
  • Viewing Angle : Normal viewing angle, 70°/70°/50°/70° (L/R/U/D)
  • Display Area(A.A): 196.6mm (W) × 147.5mm (H)
  • Resolution : 1024×768 Pixel
  • Backlight : LED
  • Brightness : DMG10768C097_03WTC : 270nit


Touch Patameters

  • Type : CTP (Capacitive touch panel)
  • Structure : G+G structure with surface cover of Asahi tempered glass
  • Touch Mode : Support point touch and drag
  • Surface Hardness : 6H
  • Light Transmittance : Over 90%
  • Life : Over 1,000,000 times touch


Voltage & Current

  • Power Voltage : 6~15V
  • Operation Current : VCC = +12V, Backlight on,270mA, VCC = +12V, Backlight off,90mA


Reliability Test

  • Working Temperature : 10℃~60℃ (5V @ 60% RH)
  • Storage Temperature : -20~70℃
  • Working Humidity : 10%~90%RH, typical value of 60% RH
