DWIN 5inch Smart LCM, Resistive Touch, IPS TFT 480x854 250nit RGB Serial Port LCM LCD Display, DMG85480C050_03WTR
This is a DWIN 5inch Smart LCM IPS TFT, Resistive Touch, IPS TFT 480x854 250nit RGB Serial Port LCM LCD Display, DMG85480C050_03WTC. The Dwin 5inch Smart LCD Touch Display Comes With 16.7 millons RGB colors 250nit brightness, Which based on T5L1n Chip, running DGUS II system, connect with any MCU even 8 bit.
Features
- T5L1n Chip, running DGUS II system, connect with any MCU even 8 bit
- 5.0-inch, 480*854 Pixels resolution, 16.7M Colors, IPS-TFT-LCD, Wide viewing angle
- Resistve touch screen
- TTL/CMOS interface; 10Pin_1.0mm connection wire
- Download via SD card or on-line serial port,USB or Wifi is optional
- Friendly-to-use DWIN DGUS V7.6 GUIs Development tool ,no coding skills required
- Double Development System:DGUSⅡ/TA(Instruction set)
- Wide viewing angle, 85°/85°/85°/85° (L/R/U/D)
- With GUI&OS two kernals ,GUI kernal with rich touch and display controls,DWIN OS kernel is open to the user for the second-development,via DWIN OS language or KELI C51.
Touch parameters
- Type : RTP (Resistive touch panel)
- Structure(CTP) : ITO film + ITO glass
- Touch Mode : Support point touch and drag
- Surface Hardness : 3H
- Light Transmittance : Over 80%
- Life : Over 1,000,000 times touch
Voltage & Current
- Power Voltage : 4.5~5.5V, typical value of 5V
- Operation Current : VCC = +5V, max backlight,260mA / VCC = +5V, Backlight off,80mA
Reliability Test
- Working Temperature :-20℃~70℃ (5V @ 60% RH)
- Storage Temperature : -30~80℃
- Working Humidity : 10%~90%RH，typical value of 60% RH
Interface
- LCM interface : FPC60_0.5mm,RGB interface
- RTP interface : FPC4_1.0mm
- CTP interface : 6Pin_0.5mm, IIC interface
- Baudrate : 3150~3225600bps, typical value of 115200bps
- Output Voltage : Output 1, Iout = -4mA;3.0~3.3 V / Output 0, Iout =4mA;0~0.3V
- Input Voltage (RXD) : Input 1；2.4~5.0V / Input 0；0~0.5V
- User interface : 10Pin_1.0mm latching socket for power supply and serial communication. Download rate(typical value): 12KByte/s / UART2: TTL/CMOS; / UART4: TTL/CMOS; ( Only available after OS configuration)
- Flash : 16MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times
- Buzzer : 3V passive buzzer. Power: <1W
- SD interface : FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s
- Reserved module interface : Wi-Fi module: connect to the cloud platform to update remotely USB module: download files by USB flash disk
- PGT05 interface : When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
