E106-915G27P2 SX1302 915MHz LoRaWAN Gateway Module - Standard Mini-PCIe Socket - SPI Interface

E106-915G27P2 module is a LoRa gateway RF module designed based on the SX1302 chip. It adopts the standard Mini PCI-e package, SPI interface, the module has built-in PA and LNA, and the half-duplex design is convenient for users to quickly develop LoRa gateway equipment.

SX1302 is a new generation LoRa gateway baseband chip launched by Semtech. It is equipped with front-end SX1250 and can support spreading factors SF5~SF12. Compared with the previous generation SX1301 gateway solution, it can support higher-speed data communication, while the power consumption is greatly reduced, the design is simplified, and the performance is significantly improved.

Datasheet

Features

PCI Express Mini Card 1.2 standard interface
Sending current max 360mA, receiving current 60mA
I-PEX antenna interface, half-duplex communication
Standard SPI digital interface
Support 8 receiving channels, SF5~SF12 full solution, receiving sensitivity as low as -141dBm
Support 1 transmission channel, the maximum transmission power is 27dBm (typical value 26dBm)
ISM band：EU433、CN470、EU868、US915

Specifications

Chip: SX1302
Host Interface: SPI
Working frequency: 902~928MHz
Power: 27dBm
Distance: 5km
LEDs Red: TX，RX
Operating temperature: -40℃~ +85℃
Size: 50.95*30*4.5mm (PCB)
