E22-900T30D UART/SX1262 868/915 MHz 30dBm DIP LoRa Wireless Module

E22-900T30D UART/SX1262 868/915 MHz 30dBm DIP LoRa Wireless Module

E22-900T30D is a wireless module (UART) based on SX1262 with multiple transmission modes, working in the 850.125MHz~930.125MHz, (default 868.125MHz). It features LoRa spread spectrum technology, TTL level output,compatible with 3.3V and 5V IO port voltage.

E22-900T30DC adopts a new generation of LoRa spread spectrum technology. Compared with the traditional SX1278 solution, it has a longer transmission distance, faster speed, lower power consumption, and smaller size; it supports functions such as air wake-up, wireless configuration, carrier monitoring, automatic relay. communication keys and sub-package length setting. Ebyte provides customized development services on it.

User Manual

Features

• SX1262 LoRa chip brings further communication distance and stronger anti-interference ability
• Supports automatic relay network, multilevel relay used in long distance communication, the same area to run multiple network running at the same time
• The communication allows users to set key that cannot be read, greatly improving the user data privacy
• Supports LBT function, before sending channel environmental noise monitoring, can greatly increase the success rate of communication module in harsh environment
• RSSI signal strength indicator function, can be used to assess the signal quality, improve the communication network and distance
• Wireless parameters configuration, sent via wireless instruction packet, or read a wireless remote configuration module parameters
• Air wake up, that is, ultra-low power consumption function, suitable for a battery-powered application solutions
• Supports fixed transmission, radio transmission, channel to monitor
• Deep sleep mode enables 2 uA power consumption
• Global free license ISM 868/915 MHZ band
• Under ideal conditions, the communication distance can be up to 10 km
• Supports parameter electricity saving, electricity again after the module will work according to set good parameters
• 3.3 V to 5.5 V power supply, over 5V power supply can ensure the best performance
• Industry-standard design, support – 40 ~ + 85 ℃ under long time use

Applications

• Home security alarm and remote keyless entry
• Smart home and industrial sensors
• Wireless alarm security system
• Building automation solutions
• Wireless industrial-grade remote control
• Health care products
• Advanced Meter Reading Architecture(AMI)
• Automotive industry applications
