Ebyte E220-900M22S LLCC68 868~915MHz 22dBm 7km Long Range LoRa Wireless Module - SPI Interface

Ebyte E220-900M22S LLCC68 868~915MHz 22dBm 7km Long Range LoRa Wireless Module - SPI Interface

E220-900m22s is an small module, self-developed based on the new generation of LoRa TM RF chip llcc68, produced by Semtech company. It is suitable for 868mhz and 915MHz LoRa TM wireless module and uses industrial 32mhz crystal oscillator.

Datasheet

Features

• The measured distance can reach 5500m
• The maximum transmitting power is 160mw, and the software is multi-level adjustable
• Support global license free ism 868 / 915MHz band
• In LoRa TM mode, the data transmission rate is 1.76kbps ~ 62.5kbps
• FSK mode supports up to 300kbps data transmission rate;
• FIFO has large capacity and supports 256 byte data cache;
• Support spread spectrum factor sF5, SF6, sf7, SF8, Sf9, SF10, SF11;
• Support 1.8V ~ 3.7V power supply, more than 3.3V power supply can guarantee the best performance;
• Industrial standard design, support - 40 ~ 85 ° C long-term use;
• Dual RF interface is optional (IPEX / stamp hole), which is convenient for secondary development and integration

Specifications

• IC: LLCC68
• Frequency: 850~930MHz
• Transmitting Power: 20dBm
• Distance: 7km
• Package: SMD

• Communication Interface: SPI
• Antenna type: IPEX / Stamp hole
• Operating temperature: -40 to +85℃
• Operating humidity: 10 to 90%
• Storage temperature: -40 to +125℃

Applications

• Home security alarm and remote keyless entry
• Smart home and industrial sensors, etc
• Wireless alarm security system
• Building automation solutions
• Wireless industrial remote controller
• Health care products
• Advanced meter reading architecture (AMI)
• Automotive industry applications
