Ebyte EBT3001 Serial Port to Ethernet Converter IC SMD - QFN-48

Ebyte EBT3001 Serial Port to Ethernet Converter IC SMD - QFN-48

EBT3001 is a serial port chip that realizes serial port data ⇌ Ethernet data conversion. It has a variety of Modbus gateway modes and MQTT/HTTP IoT gateway modes, which can meet the networking functions of various serial devices/PLCs.

Datasheet

Features

• Support multiple working modes ( TCP Server , TCP Client , UDP Server , UDP Client )
• Support web page setting, configuration tool setting, AT command setting parameters
• Support multiple socket connections
• Support multiple checksums ( None , Odd , Even , Mark , Space )
• Support DHCP function
• Support DNS function, domain name resolution
• DNS server address customization
• Support a variety of Modbus gateways (simple protocol conversion, multi-host mode, storage gateway, configurable gateway)
• Supports quick access to Alibaba Cloud, Baidu Cloud, One NET , Huawei Cloud, and standard MQTT servers of version 3.1
• Support HTTP protocol ( GET/POST request)
• Support virtual serial port
• Support timeout restart function, restart time customization
• Support short connection function, short connection interval time customization
• Support heartbeat package and registration package functions
• Support cache cleaning function
• Support access to external network and local area network
• Independently design test suites, which are convenient for users to debug and use
• Support online upgrade function.

Specifications

• Operating voltage: 2.1V~3.6V(DC)
• Serial port level: TTL level (3.3V)
• Working mode: TCP Server, TCP Client, UDP Server, UDP Client, HTTP Client, MQTT Client (default TCP Server)
• Socket connection: Supports 6-way client connection (TCP server mode)
• Network protocols: IP, TCP/UDP, IPv4
• Network caching: 512 Byte
• Serial port caching: 512 Byte
• Serial port baud rate: 1200 to 230400 bps (default 115200)
• Operating temperature and humidity: -40 ~ +85°C, 5% ~ 95% RH (non-condensing)
• Store temperature and humidity: -40 to +105°C, 5% to 95%RH (non-condensing)
