Ebyte NE2-S1 TTL Serial Port to Ethernet Patch Module

Ebyte NE2-S1 TTL Serial Port to Ethernet Patch Module

NE2-S1 single serial port server module is a serial port to Ethernet module that realizes bidirectional transparent transmission of serial port and Ethernet data. Users do not need to care about the specific details, and the protocol conversion is completed inside the device. It has a variety of Modbus gateway modes and MQTTC/HTTPC IoT gateway modes, which can meet the networking functions of various serial devices/PLCs. it adopts industrial-grade design standards to ensure equipment reliability. This Ethernet module uses a 1.27mm stamp hole interface and is compact in size, making it easy for users to integrate into the system.

Datasheet

Features

• Supports 10 /100M Ethernet interface , cross-direct connection adaptive
• The product supports 2-way Socket, each channel supports TCP Server, TCP Client, UDP Server, UDP Client, HTTPC , MQTTC
• Supports three configuration methods: configuration tool, web page, and AT command
• Server mode supports 5- way Socket connection
• Support DHCP function
• Supports DNS (domain name resolution) and can customize the domain name resolution server
• Supports a variety of Modbus gateways (simple protocol conversion, multi-host mode, storage gateway, configurable gateway , active upload mode )
• Supports quick access to Alibaba Cloud, Baidu Cloud, OneNET, Huawei Cloud, and version3.1.1 standard M QTT servers
• Support HTTP protocol ( GET/POST request)
• Support virtual serial port
• Supports disconnection reconnection and timeout restart functions
• Supports Keepalive mechanism, which can quickly detect network abnormalities and quickly reconnect
• Supports short connection function and can customize short connection interval
• All modes support heartbeat package and registration package functions
• Support access to external network and local area network
• Supports one-click restore to factory settings
• Support online upgrade function.

Specifications

• Interface signal: Ethernet
• Operating mode: TCP Server (default), TCP Client, UDP Server, UDP Client, HTTP Client, MQTT Client
• Network protocol: TCP/UDP, MQTT, HTTP, IPv4, DHCP, DNS
• Operating Voltage: DC 3.1~6V (VCC1) - DC 3.0~3.6V (VCC2)
• Working current: Peak value: 180mA@5V(VCC1); [email protected](VCC2) - Standby: 50mA@5V(VCC1); [email protected](VCC2)
• Working temperature and humidity: -40~+85℃, 5%~95%RH (no condensation)
• Storage temperature and humidity: -40~+105℃, 5%~95%RH (no condensation)
• Product Size: 19×17mm (L×W×H)
