Ebyte NS1 Serial to Ethernet Converter Module SMD

NS1 is a serial server that realizes serial data ⇌ Ethernet data conversion. It has a variety of Modbus gateway modes and MQTT/HTTP IoT gateway modes, which can meet the networking functions of various serial devices.

Datasheet

Features

RJ45 supports 10M Ethernet interface
Support multiple working modes (TCP Server, TCP Client, UDP Server, UDP Client, HTTPC, MQTTC)
Support configuration tools, web pages and AT commands
The server mode supports multiple socket connections
Support multiple baud rates
Support DHCP function
Support DNS (domain name resolution) and customizable domain name resolution server
Support multiple Modbus gateways (simple protocol conversion, multi-host mode, storage gateway, configurable gateway)
Support fast access to Alibaba Cloud, Baidu Cloud, One NET, Huawei Cloud, and version3.1standard MQTT servers
Support HTTP protocol (GET/POST request)
Support virtual serial port
Support timeout restart function and customize the restart time
Support the short connection function and customize the short connection interval
Support heartbeat package and registration package functions
Support serial port cache cleaning function
Support access to the Internet and LAN
Support hardware restoration to factory settings
Support online upgrade function

Specifications

Interface: TTL(3.3V) to Ethernet port (RJ45)
working voltage: DC 3.0〜5V
Working current: Standby: 30mA @ 3.3V Peak: [email protected] Standby: 25mA @ 5V Peak: 250mA@5V
Serial port level: 3.3V TTL level, if 5V is required, external conversion circuit is required
Working mode: TCP Sen-er (default), TCP Client UDP Server, UDP Client, HTTP Client MQTT Client
Socket connection: TCP server supports 6-way client connections
Network protocol: TCP/UDP、MQTT、HTTP、IPv4、DHCP、DNS
IP acquisition method: Static IP (default), DHCP
Serial port cache: 1024 Byte
Packaging mechanism: 512 Byte
Serial baud rate: 1200〜23 0400 bps (115200 by default)
Product size: 17 x 19 x 4mm (L x W x H)
Working temperature and humidity: -40^+85。(2, 5%-95% RH (no condensation)
Storage temperature and humidity: -40〜+105 ℃; 5%〜95% RH (no condensation)
