Ebyte NE2-T1 TTL Serial to Ethernet Transmission Module

Ebyte NE2-T1 TTL Serial to Ethernet Transmission Module

NE2-T1 single serial port server module is a super network port used to realize bidirectional transparent transmission of data from the serial port to the Ethernet port. Users do not need to care about the specific details, and the protocol conversion is completed inside the server. It has a variety of Modbus gateway modes and MQTTC/HTTPC IoT gateway modes; it adopts industrial-grade design standards to ensure device reliability. The product comes with an RJ45 interface, pin package, and is easy to use due to its compact size (also known as "super network port"). It can meet the networking functions of various TTL level serial devices and MCU/PLC.

Datasheet

Features

• RJ45 supports 10 / 100M Ethernet interface, cross-connect direct adaptive
• The product supports 2-way Socket, each channel supports TCP Server, TCP Client, UDP Server, UDP Client, HTTPC , M QTTC
• Supports three configuration methods: configuration tool, web page, and AT command
• Server mode supports 5-way Socket connection;
• Support DHCP function
• Supports DNS (domain name resolution) and can customize the domain name resolution server
• Supports a variety of Modbus gateways (simple protocol conversion, multi-host mode, storage gateway, configurable gateway, active upload mode)
• Supports quick access to Alibaba Cloud, Baidu Cloud, One NET , Huawei Cloud, andversion3.1.1 standard M QTT servers
•  Support HTTP protocol ( GET/POST request)
• Support virtual serial port
• Supports disconnection reconnection and timeout restart functions
• Supports Keepalive mechanism, which can quickly detect network abnormalities and quickly reconnect
• Supports short connection function and can customize short connection interval
• All modes support heartbeat package and registration package functions
• Support access to external network and local area network
• Supports one-click restore to factory settings

Specifications

• Interface mode: TTL serial port + RJ45
• Working voltage: DC 3.1~6V
• Transmission medium: network cable
• Product size: 34.86×22×25mm (L×W×H)
• Operating Voltage: DC 3.1~6V, such as 5.0V power supply, the power supply load capacity is recommended to be more than 300mA
• Working current: Peak: 180mA@5V; [email protected] Standby: 50mA@5V; [email protected]
• encapsulation: 2.54mm pin header
• Operating mode: TCP Server (default), TCP Client, UDP Server, UDP Client, HTTP Client, MQTT Client
• Socket connection: A single link placed by the TCP server supports 5 client connections
• Network protocol: TCP/UDP, MQTT, HTTP, IPv4, DHCP, DNS
• How to obtain IP: Static IP (default), DHCP
• Working temperature and humidity: -40~+85℃, 5%~95%RH (no condensation)
• Storage temperature and humidity: -40~+105℃, 5%~95%RH (no condensation)
