ESP32-GEEK Development Board, Based On ESP32-S3R2 Controller Chip, With 1.14inch 65K Color LCD, Supports WiFi & Bluetooth LE

Waveshare ESP32-GEEK Development Board, Based On ESP32-S3R2 Controller Chip, With 1.14inch 65K Color LCD, Supports WiFi & Bluetooth LE, USB-A Male Port, With White Plastic Case

ESP32-S3-GEEK is a geek development board designed by Waveshare, onboard USB-A port, 1.14inch LCD screen, TF card slot, and other peripherals. Supports 2.4GHz WiFi and BLE 5, with integrated 16MB Flash & 2MB PSRAM, provides I2C port, UART port, and GPIO header, bringing more possibilities for your project.

The ESP32-GEEK Development Board, a feature-rich and versatile platform built around the powerful ESP32-S3R2 controller chip. This development board is designed for enthusiasts, makers, and developers seeking a compact yet robust solution for IoT and wireless communication projects. With a host of capabilities, including a vibrant 1.14-inch 65K color LCD display and support for both WiFi and Bluetooth Low Energy (BLE), the ESP32-GEEK opens up a world of possibilities for your creative endeavors.

User Manual / Datasheet / Example Codes Etc.

Key features

• Adopts ESP32-S3R2 chip with Xtensa 32-bit LX7 dual-core processor, capable of running at 240 MHz
• Built in 512KB SRAM, 384KB ROM, 2MB of on-chip PSRAM, and onboard 16MB Flash memory
• Onboard 1.14inch 240×135 pixels 65K color IPS LCD display
• Integrated 2.4GHz WiFi and Bluetooth LE dual-mode wireless communication
• WiFi supports Infrastructure BSS in Station, SoftAP, and Station + SoftAP modes
• WiFi supports 1T1R mode with data rate up to 150 Mbps
• Bluetooth supports high power mode (20dBm)
• Internal co-existence mechanism between Wi-Fi and Bluetooth to share the same antenna
• Onboard 3PIN UART port, 3PIN GPIO header and 4PIN I2C port
• Equipped with plastic case and cables
• Provides online open-source demo and resources, more convenient for learning and development

ESP32-S3 GEEK Development Board

Integrated LCD Screen, TF Card Slot, Boot Button and Other Peripheral interfaces

Combines Multi Functions In One

Onboard Multi Interfaces And 1.14inch LCD Display, Combines With

WiFi & Bluetooth For More Possibilities

Package Includes

Onboard Resources

1.  USB-A interface

2.  UART port

3.  GPIO header

4.  I2C port

5.  TF card slot

6.  W25Q128JVSIQ

• 16MB NOR-Flash

7.  ESP32-S3

8.  BOOT button

9.  Onboard antenna

Dimensions
