Name: P3 Indoor RGB Full-Color LED Matrix Panel, 3mm Pitch, 64×64 Pixels, Adjustable Brightness
Brand: GKGD
SKU: 05367
Price: 2269.00 INR
Availability: InStock

P3 Indoor RGB Full-Color LED Matrix Panel, 3mm Pitch, 64×64 Pixels, Adjustable Brightness

GKGD

P3 Indoor RGB Full-Color LED Matrix Panel, 3mm Pitch, 64×64 Pixels, Adjustable Brightness

Based on 0 reviews. - Write a review

₹2,269.00

₹1,922.88 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 19
B2B GST Credit Available

Price in reward points: 1923

Stock: 16 in Stock
SKU: 05367
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

This RGB LED matrix panel consists of total 4096 (64*64) individual RGB LEDs. Each of these LEDs are spaced from each other by 3mm. The fine pitch of just 3mm enables this RGB matrix for applications such as graphics display/ images display etc. This panel can be driven through Arduino/ STM32/ESP32/ Raspberry Pi etc. It allows driving of the LEDs through a standard HUB75 data protocol interface.

Features

4096 individual RGB SMD2020 LEDs, full-color display, adjustable brightness
1/32 Scanning.
64×64 pixels, 3mm pitch, allows displaying text, colorful image, or animation
192×192x14mm dimensions, moderate size, suitable for DIY desktop display or wall mount display
Onboard two HUB75 header, one for controller data input, one for output, chain support
Provides open source development resources and tutorials, for use with Raspberry Pi, Arduino, and so on

Technical Datasheet [PDF]

Arduino Example Codes

Specifications

DIMENSIONS	192mm × 192mm
PIXELS	64×64=4096 DOTS
PITCH	3mm
PIXEL FORM	1R1G1B
VIEWING ANGLE	≥160°
CONTROL TYPE	synchronization
DRIVING	1/32 scan
HEADER	HUB75
POWER SUPPLY	5V / 4A (VH4 header input)
POWER	≤20W

PIN	DESCRIPTION	PIN	DESCRIPTION
+5V	5V power input	GND	Ground
R1	R higher bit data	R2	R lower bit data
G1	G higher bit data	G2	G lower bit data
B1	B higher bit data	B2	B lower bit data
A	A line selection	B	B line selection
C	C line selection	D	D line selection
E	E line selection	CLK	clock input
LAT/STB	latch pin	OE	output enable

Chainable Design

Multi LED Matrix Panel Can Be Chained Together To Build A Larger Panel
Via HUB75 Input/Output Header

Each RGB LED matrix panel requires a standalone 5V/4A or above power supply, when they're chained to display.

Usage Scenarios

DIY Maker Desktop Or Wall Mount Display, Signboard, Environment Monitor...

Dimensions
